Discover Acti9 C120
Discover Acti9 C120
Get maximum safety and continuity of service
Acti9 C120 circuit breakers are especially suited for the protection of electrical circuits in all commercial and industrial buildings. They ensure: • Protection of circuits against short-circuit currents and overload currents • Protection of people and equipment against earth leakages • Isolation of building applications according to IEC/EN 60898-1 standard • Isolation in the industrial sector according to IEC/EN 60947-2 standard • Tripping and signalling on fault by adding auxiliaries
Benefits of Acti9 C120
Benefits of Acti9 C120
Enhanced protection
Prevention and protection of people and equipment from electrical threats
Reliability
Increased reliability due to the fast closure which is independent of toggle operating speed
Service continuity
Good overvoltage withstands capacity and high industrial performance level: • Degree of pollution • Rated impulse withstand voltage • Insulation voltage
Controller / PLC architecture integration
Remote indication of the open, closed or tripped state by auxiliary contacts from 2mA (optional)
Features
Features
• Nominal current: 63 to 125 A • Breaking capacity: up to 15 kA (400 V AC) • Tripping curves (B, C, D) • Compliant with IEC/EN 60898-1 or IEC/EN 60947-2 • Operating voltage: up to 440 V AC • Insulation voltage: 500 V AC • IP20 terminal insulation
• Add-on residual current device modules: Acti9 C120 Vigi • Pole types: 2P / 3P / 4P • Protection types: AC, A • Sensitivity: 30, 300, 500, 1000 mA
• Indication auxiliaries: OF, SD, OF/SD+OF • For basic (from 100 mA to 6A) and Advanced (from 2 mA to 100 mA) applications • Compliant in harsh environments with low current auxiliaries • Optimise your wiring (fewer wires and wiring time) inside a panel with the daisy chain architecture with low current auxiliaries. Monitoring up to 100 protective devices (permanently closed) under the daisy chain.• Select the right offer: • For basic applications, use the version from 100mA to 6A commercial reference A9N2690x. • For low current application and daisy chain, use the commercial reference A9N2691x.• Tripping auxiliaries: MN, MX • Instantaneous or delayed • Option: independent of the supply voltage• Acti9 accessories • Acti9 27mm comb busbars • Linergy DS screw distribution blocks • PowerTag Energy
Applications
Applications
Commercial buildings
Explore moreIndustrial buildings
Explore more
