Discover SpaceLogic Butterfly Valves and Actuators

Benefits of SpaceLogic Butterfly Valves and Actuators

Energy efficient

Available with adjustable limit switches and end stops to limit flow to design specifications for the most efficient heat transfer.
Flexible

Valves are suitable for a diverse water medium and approved for drinking water, compatible with actuators supporting all common control signal types.
Resilient

Valve bodies feature nylon 11 or SS discs, reducing friction loss. Engineered for bidirectional bubble-tight shutoff and media isolation.
Low maintenance

The tongue and groove seat design, along with the moulded O-ring, eliminates the need for flange gaskets and simplifies seat maintenance or replacement.

Features

Assemblies

All assemblies include industry-leading butterfly valve features, stainless steel shafts, nylon 11-coated ductile iron disc machined to provide bubble-tight shut-off, minimum torque, and longer seat life. All 3-way valve configurations are shipped factory-assembled with the appropriate linkage kit.

Control

The high-pressure butterfly valve meets heavy-duty HVAC needs and can be used as a manual isolation valve or motorised by using various actuators. These actuators are ideal for use on valves for chillers, cooling towers, boilers, heat exchangers, and other outdoor applications.

Design

The resilient seated butterfly valves feature a one-piece body with a high strength through stem design utilising an internal disc to stem connection thereby improving strength and serviceability. Precision double "D" disc to stem connection drives the disc without the need for screws or pins.

Easy installation

The actuators are a direct fit not requiring any linkage kits simplifying and reducing installation time. Actuators provide visual position indication on all models and are IP65/NEMA 4 rated, including integrated heaters for outdoor/rooftop use. The manual de-clutchable override handwheel is standard on all S70 actuators providing end-user convenience in installation, commissioning, and service.
