Discover Altivar Lift

Benefits of Altivar Lift

Advanced functions

Half-floor control, inspection mode, rollback management, direct to the floor, evacuation with UPS, load measurement, deferred thermal stop, etc.
High-quality drive

Drives with the S337 or 337 extensions are designed for use in difficult environmental conditions (class 3C2 in accordance with IEC 721-3-3).
Programming simplicity

Intuitive menu for lift installers with application-specific terms and units (kg, cm, m/s, m/s² etc.)

Features

Facts about Altivar Lift

Variable speed drives for synchronous and asynchronous motors (with or without encoder) • 200/240 V range - 27 A to 66 A • 380/480 V range - 10 A to 48 A Maximum benefits for all users For lift passengers: • Smooth starting and stopping • Fluid movements • Optimum speed (minimum travel time) • Accurate stopping • Silent operation For the service technician: • Communication tools adaptable to each application (PC, remote graphic display terminal, and Simple Loader®) • Ease of maintenance with a monitoring menu, which includes the distance traveled, number of journeys, etc., and a diagnostics menu that lists faults and their context (lift car speed, line voltage, motor current, etc.) For the building owner: • Reduced machine wear due to fewer mechanical shocks • Greater energy savings achieved by optimizing drive power consumption
