Discover P25M
Discover P25M
Enhanced protection for greater efficiency
The P25M motor protection circuit breaker is designed for optimal efficiency and ease of use in all modular final distribution enclosures. With a rating of up to 25 A, this 9 Series device features advanced thermal trip protection and optional auxiliary components. The P25M provides dependable motor protection for both commercial and industrial environments, ensuring straightforward and effective installation across various applications.
Benefits
Benefits
Easy installation
Flexible
Easy to handle
Robust
Features
Features
Facts about P25M
- Rating current: 0.16 to 25 A.
- Breaking capacities: 15 kA under 400/415 V.
- Complete with thermal trip: sensitive to underphase; magnetic trip: 12 In.
- Fully compliance with standards: IEC 60947-2, IEC 60947-4-1.
- Fully certified by national official authorities.
- Ideally suited to isolation in full accordance with industrial standards: IEC 60947.
- Operating voltage: up to 690 Vac.
- Insulation voltage: 690 V.
- Benefit from an optional add-on limiting unit: breaking power increased to 100 kA under 400/415 V.
- Optional auxiliaries available: indication of state and tripping, shunt trip, undervoltage trip.
