Designed for low voltage electrical network
When designing a new installation or expanding an existing one, Electrical calculation tools allow you to quickly select a protection device, check selectivity and calculate the cables. The electrical calculation tools are based on our ecodial electric network calculation software. The new online software tools are gradually replacing Curve Direct and direct Coordination. These tools suggest a report-generation function. No download required. Direct access from web browser. Can run on PC and tablet.
Benefits of Electrical calculation tools
Benefits of Electrical calculation tools
Easier and faster to use
Easier to use than paper catalogues and coordination tables, and faster than heavy-duty electrical network calculation software.
Up to date
Stay informed with our low-voltage protection products and circuit breakers.
Convenience
You don't need to download or resident software package on your computer. Online tools can be accessed from your web browser, and it’s on.
Features
Features
Facts about Electrical calculation tools
- Display the time-current curves of 1 to 8 circuit-breakers.
- Check the discrimination between two circuit-breakers and display their time-current curves.
- Search all the circuit-breakers that can be selective with a defined circuit-breaker.
- Search all the circuit-breakers that offer cascading with a defined circuit-breaker.
- Display the curves of two Residual Current Devices (RCD) and check their discrimination.
- Calculate the Cross Section Area of cables and build a cable schedule.
- Calculate the voltage drop of a defined cable and check the maximum length.
