Modicon B883-200 Thermocouple Input Module
This document is current but may reference obsolete products.
The Modicon B883-200 Thermocouple Input Module is a smart I/O module that multiplexes up to ten thermocouples into three consecutive input registers of the control system. Any mix of type B, E, J, K, R, S, T, or N thermocouple operations or simple -20 to +80 mV input operations may be set by the user under program control. There are two user manuals attached: Manual 1 is 3.06 MB Manual 2 is 4.78 MB Both are PDF format
Date:
01 May 1994
|
Type:
User guide
Languages:
English
|
Version:
1
Document Reference:
GIB883200
Files
| File Name | |
|
B883-200_UserManual1of2.pdf
|
|
|
B883-200_UserManual2of2.pdf
|
|
Related products
Product Ranges:
-
800 series IO -
984/800 IO
