Discover Acti9 Smartlink

Acti9 Smartlink connects Acti9 devices in one click for easy integration with the facility management system to monitor, control, and meter Acti9 modules in distant distribution panels. It seamlessly adapts to the dynamic demands of tertiary and industrial applications for:

Load monitoring
Load control switching
Energy metering

Benefits of Acti9 Smartlink

Energy optimization
Automation, scheduling, and control of remote equipment to optimize energy consumption and reduce operation costs.
Data from electrical distribution boards in real-time contributes to achieving energy efficiency targets.
Data analysis
Collection, visualization, and analysis of data from energy meters for individually monitored/controlled circuits in multiple distribution panels.
Instant, precise, and detailed warnings in the event of power loss.
Remote control
Simplicity of upgrading existing installations for remote monitoring and control.
Possibility to combine one Ethernet version with Modbus slaves, allowing for as many inputs as required on large installations.
Native integration
Native integration to COMX510 to access energy dashboards at the building level.
Integration with spaceLYnk for simple scheduling or SBO automation server for our Building Management System (BMS).

Features

Facts about Acti9 Smartlink

Main features:

Status and alarms from circuit breakers
Remote control of contactors
Remote monitoring of metered values
DIN rail fitting: no additional space needed
Simple, rapid installation with ready-to-connect communication module
All-in-one cables with pluggable connections
IEC 61131 compliant (PLC I/O modules)
24 V DC power supply Acti9 Smartlink SI B:
7 digital input/output channels and 2 analog inputs
Connection with up to 20 wireless devices
RS485 Modbus Master communication (up to 8 Acti9 Smartlink Modbus or other Modbus slaves) Acti9 Smartlink Modbus:
11 digital input/output channels
RS 485 Modbus Slave communication.
