iC60

With exclusive features, the Acti9 iC60 DIN rail miniature circuit breakers have been specifically designed to provide first-rate protection and continuity of service.

• VisiSafe: provides protection during maintenance work on downstream circuits
• VisiTrip: signals with a redflag the faulty miniature circuit breaker outgoers to reduce intervention time
• Class-2 insulation: double insulation distance to ensure continuous protection for both operators and unqualified persons
• Pollution Class 3 for operation in more polluted environments such as some industrial applications
• Fully compliant with standards IEC/EN 60898-1 and IEC/EN 60947-2
• Add-on fully immune Acti9 iC60 Vigi earth leakage protection devices: improved continuity of service, especially in polluted environments and networks
• Offers a wide range of electrical auxiliaries: remote indication of Acti9 iC60 status and several tripping actuators: shunt trip, undervoltage trip, overvoltage trip.

Acti9 iC60 MCBs belong to Acti9 complete electrical system providing protection, monitoring and control of your electrical installation.

• Full system and electrical compatibility with the Acti9 range and with compact NSX molded case circuit breakers (MCCBs)

• Acti9 iC60 miniature circuit breakers are divided in three ranges Acti9 iC60N, iC60H and iC60L to cover your electrical requirements:
  •Nominal current: 1 to 63 A
  •Large choice of breaking capacities— up to 100 kA— and tripping curves: B, C, D, K, Z and MA

• Suitable for isolation in compliance with industrial standard IEC 60947
• Operating voltage: up to 440 V AC, insulation voltage: 500 V.

Complete with VisiSafe and VisiTrip, Acti9 iC60 miniature circuit breakers expertly combine reliability, protection and ease of use.

• Set a new benchmark in final distribution circuit breakers
• Enhanced security when it comes to circuit protection thanks to VisiSafe
• Provide greater continuity of service thanks to VisiTrip
• Come with easily identifiable part numbers, making Acti9 iC60 miniature circuit breakers simple to order and use
• Easy installation with quick and ergonomic IP20B terminal shutters
• Highly durable with robust connections that provide twice the standard tightening torque
• Environmentally friendly with 100% recyclable and recoverable materials.

Providing essential protection in industrial and commercial buildings, our miniature circuit breakers work especially well in polluted environments and networks.

• For the enhanced protection of electrical circuits in all types of industrial and commercial buildings
• Suitable for all settings, particularly polluted environments and networks
• Motor circuit protection
• DC current circuit protection.
