Discover TeSys Deca - frame 4

Benefits

Save time

• Simple to specify, install and use for all applications • Dual class to reduce commercial references • Smartphone access to facilitate maintenance on site
Improve efficiency

• Compact, space-saving design • One-click accessories with spring terminal • Externally visible auxiliaries
Increase safety

• 90-year history of engineering • EverLink technology ensures a lasting connection • Double rotary contact improves breaking capacity as Compact NSXm • Reflex tripping mechanism for double protection during short circuit

Features

Facts about TeSys Deca - Frame 4

• Covers motor protection from 0.25 to 55 kW at 415 V AC (from 0.8 to 115 A) all in one frame • Available in three different breaking capacities: - 25, 50, and 100 kA at 415 V AC IEC (15, 35, 65 kA at 480 V UL) • Patented EverLink creep-compensating technology - Spring-based system ensures a long-lasting connection - Improves overheating leading to a trip - Reduces risk during short circuits • Ergonomic rotary handle for easy switching and controlling with clear trip indication. Other options include: - Toggle - Side - Extended • Available in three different versions: • Type L: Magnetic short circuit protection to be used with an overload relay or a drive • Type P: Magnetic short circuit and overload protection - Electronic core for high-accuracy, wide settings, dual motor class 10/20 • Type PEM: Magnetic short circuit and overload protection with advanced settings and pre-alarming - SDx side module available for alarming and fault differentiation (GV4 PEM)
