Discover TeSys T

Benefits of TeSys T

Easy to install

Having a central control in TeSys T will reduce the complexity of your installation. It can be controlled through its terminal strip, HMI or communication port.
Robust

The TeSys T range is designed for the management of critical processes in a harsh environment.
Reliability and durability

As a product TeSys T has an all-in-one design and advanced electronic protection, which makes it a highly reliable and durable product.
Low power consumption

The power monitoring capabilities make TeSys T a green motor management system because it can help manage energy consumption.

Features

Facts about TeSys T

The TeSys T motor management system provides protection, metering and monitoring functions for single-phase and 3-phase AC motors up to 1000 A. TeSys T is a smart system that can be adapted to any customer request with Custom Logic and is natively connected to any PLC on 6 protocols. The range is comprised of three components:

Main controller provides current-based protection and monitoring, communication, control and statistics features.
Optional expansion module adds voltage, power and energy measurement.
HMI is a flexible option to quickly monitor and commission a TeSys T system. Control features are also available through the HMI.

Flexibility

Fully open, it communicates with Ethernet protocols: Modbus/TCP and EtherNet/IP, Modbus, CANopen, DeviceNet, PROFIBUS DP protocols.

Designed to fit in IEC and NEMA MCC , it integrates 10 predefined control schemes and one custom mode that let adapt control mode, product behaviour and even protections to any requests.

TeSys T can be controlled through its terminal strip, HMI or communication port. Having a central control in TeSys T will reduce the complexity of your installation, reduce the need of auxiliary equipment, save space and reduce costs.

Fully integrated into Blokset, Okken and Model 6 iPMCC TVDA, Advantys STB solution and in the Foxboro DCS.

Trust

TeSys T is highly reliable and has a very long product life thanks to a state-of-the-art component selection (FRAM memory, Flexrigid PCB, etc.) to the all-in- one design and advanced electronic protection.

TeSys T Ethernet version enjoys daisy chain loop for higher redundant system.

Prediction and Energy Management

TeSys can accurately monitor current, voltage and power over a wide range and features advanced protection and warning functions. This accuracy is key for effective protection and preventive maintenance.
