Discover Modicon Edge I/O NTS

Benefits of Modicon Edge I/O NTS

Save time

From pre-sales to operations, with adaptive tools, simpler design and wiring, quicker start-up of new machines and processes for less time to market.
Reduce cost

And reduce unplanned downtime thanks to robust design featuring environmentally hardened options, hot swap capabilities, integrated diagnostics.
Increase flexibility

With large choice of versatile modules of compact design, realising more I/O modules and more functionalities in less space.
Data-driven and cybersecure

System’s compliance with cybersecurity regulations, allowing end users to securely access and integrate the data they need.

Features

Edge I/O NTS is robust by design

Robustness demonstrated with Railway certification compliance

Standard version (-20..+60°C)

Hardened version (-40..+70°C with conformal coating)

Operate in a severe environment (Gx), with a hardened version

Hazardous location (Zone 2)

Exceed EMC industrial standard

Accept vibration up to 2g
Up to 32 modules per cluster

Up to 250 modules, and 25 clusters per island with advanced Head

No compromise on resolution with 16-bits

Synchronised internal bus

Integrated functions (Reflex output, CAMswitch, HART communication, Field Device Master communication)

OPC UA Server for explicit communication
Designed in 3 parts Base, I/O module, and Terminal block

The Base doesn’t contain any active electronic component reducing significantly the risk of failure

Hot-swappable modules

RSTP accepting 1 network failure

Work on Hot Standby architecture with Modicon M580 HSBY
In EcoStruxure Machine, Control and Automation Expert

Dedicated tool integrated into the webserver, Modicon Edge I/O NTS – Web interface, or available as software, Modicon Edge I/O Configurator

Each one shares the same experience from design to configuration, use the same configuration file.

Modicon Edge I/O Web interface and Configurator allow Commissioning w/o PLC or export EDS file

Ease operation with EcoStruxure Automation Device Manager for fleet FW update

Manage cybersecurity policies across your Schneider device with EcoStruxure Cybersecurity Admin Expert

Save time in design and get BOM in simple manner your island with Modicon PLC Configurator

Create full architecture with EcoStruxure Architecture Builder
Modicon Edge I/O NTS offers the choice between more than 100 different types of modules

Compact version allowing even more features in less space

Module can be versatile, as Analogue Input module 8 channels offer configurable choice per channel between Voltage and Current

Edge I/O NTS can be mixed with Modicon X80 in M580 CPU ring
Edge I/O NTS integrates cybersecurity by design, this is not a layer added on weak product

Ready for the evolution of cybersecurity regulations (such as Cyber Resilience Act, NIS 2.0,...)

Compliant with IEC62443-4-1, IEC62443-4-2, SB327, GDPR

Device Genuineness provides digital identification of our products (Manufacturer certificate)

Authenticated communication on the Internal bus.

Head is equipped with a Trusted Platform Module (TPM) to get cybersecurity from hardware design

Encrypted communications (Service)

Signed firmware, Simple Certificate Enrolment Protocol (SCEP), Role Based Access Control (RBAC)

Cybersecurity policies managed with EcoStruxure Cybersecurity Admin Expert

Easy to integrate into IT cybersecurity infrastructure
Design starts with user needs some customers have been integrated from the design phase

Removable terminal blocks can stay fixed even when unplugged

Select between Screw or Spring, with or without cover for your Terminal blocks

Comfortable wiring with 1 column arrangement

Voltage probe measurement even with a spring connection

PIN numbering on the Terminal block and PIN assignment on the module side

Maintenance information and online documentation are accessible from QRcode printed on the product

New packaging style reducing by 58% the quantity of cardboard

Easy to recycle with flat cardboard after opening

Paper of the Instruction sheet reduced by 75%
