Discover PanelSeT PLA
Discover PanelSeT PLA
Best in class floor-standing enclosures
- Fibreglass reinforced polyester floor-standing enclosure.
- Suitable for indoor or outdoor use.
- Harsh environment resistant.
- Long life durability in a wide range of temperatures.
- Version with canopy, maintaining the quality of the seal outdoors.
- Version with integrated plinth and open bottom for easy cable entry.
Benefits of PanelSeT PLA
Benefits of PanelSeT PLA
Robustness
- Hard impact and vandalism resistant.
- Water and dust sealed.
- Unaffected by wind or vibrations.
- Corrosive environment and chemical agents resistant.
- Long life lasting without maintenance.
Wide offer range
- Large range of dimensions (230 configurations available).
- Options for doors (plain, anti-posting, glazed).
- Multiple possibilities of installation (ground, plinth, wall).
- Large range of accessories including lamps, coupling kit, and mounting equipment.
- Customisation available (colour, cut-out, accessories).
Safety
- Self-extinguishing 960ºC test withstanding.
- Halogen-free material.
- Electrical insulation class II.
- Locking system out of the sealed area.
Features
Features
Facts about PanelSeT PLA
Floor-standing, fibreglass reinforced polyester enclosures and accessories
4 versions of enclosures are available:
- Totally sealed, IP65.
- Open bottom with integrated plinth, IP54.
- Ventilated canopy, IP44.
- Open bottom with integrated plinth and ventilated canopy, IP44.
- Height from 500mm to 2000mm. Width from 500mm to 1250mm. Depth of 320mm, 420mm, and 620mm.
- 1 door version for 500 and 750-mm width enclosures.
- 2 doors version for 1000 and 1250mm width enclosures.
- 2 doors in vertical for 2000mm height enclosures.
- Lock or handle with locks, with 2 or 4 action points out of the sealed area.
- 3 types of doors: plain, anti-posting, and glazed.
- Impact resistance: IK10 for the plain door version, IK08 for the glazed door.
- Self-extinguish: 960ºC test withstanding.
- RAL7035 colour.
- IEC62208 enclosure standard - Bureau Veritas and DEKRA.
- Bureau Veritas - marine applications.
- UL508A - CAN/CSA-C22.2 (Only for NSYPLA).
Applications
Applications
Infrastructures and Telecommunications
Solar
Marine and Water and Wastewater
Mobility and Transport
PanelSeT PLA driving sustainability
PanelSeT PLA driving sustainability
Go green with PanelSeT PLA
- PanelSeT PLA comes in packaging made of recycled cardboard.
- PanelSeT PLA products are green premium labelled.
- Complete environmental information available.
Sustainable enclosures
- PanelSeT enclosures are made in Europe to ensure short transport distances.
- PanelSeT enclosures are pre-set in the SE digital logbook, the paperless and sustainable documentation for circuit diagrams, maintenance plans, and other documents that are added to the installation along the value chain.
