Discover TeSys LE
Discover TeSys LE
An innovative motor control solution
TeSys is an innovative motor control and management solution from the global market leader. It offers connected, efficient products and solutions for switching and protection of motors and electrical loads in compliance with all major global electrical standards. It is enigmatically designed, compact, and easy to install solution.
Benefits of TeSys LE
Benefits of TeSys LE
Compact and easy to install
TeSys LE Enclosed motor starter provides flexible installation for local motor control in a harsh environment exposed to dust, vaper and water jet.
Safety
IP 65 degree of protection in harsh conditions.
Economical
Simplify your life by reducing maintenance cost and increasing safety along with reliability.
Features
- Available in both reversing and non-reversing starters.
- Confirms to standards IEC 60947-4-1.
- IP 65-degree protection.
- Ambient air temperature: operation from -5 to +40 C.
- For supply voltages between 380 and 440 V. Control circuit is pre-wired between phases. For any other supply voltages, the control circuit must be wired by the customer.
- Overload relay must be ordered separately except LE1M pre-configured range.
- Operating positions: similar to contactors.
- Enclosure Material: LE2 K and LE D09-D35 in Polycarbonate, LE D40A-D65A in Sheet Steel.
- Direct on-line LE4, LE8 range fuse switch-disconnector, contactor and overload relay Up to 15 kW.
- Available in both reversing and non-reversing starters.
- Conforms to standards IEC 60947-4-1.
- IP 65 degree of protection.
- Ambient air temperature: Operation from -5 to +40 C.
- For supply voltages between 380 and 440 V. Control circuit is pre-wired between phases. For other supply voltages, the control circuit must be wired by the customer.
- Overload relay must be ordered separately, same as for fuse.
- Enclosure material: Polycarbonate.
- LE1GV Enclosure for thermal magnetic circuit breaker + contactor Up to 5.5 kW.
- Conforms to standards IEC 60947-4-1.
- IP 55 degree of protection.
- Material: Polycarbonate.
- Star-delta LE3 range contactors + overload relay Up to 30 kW.
- Conforms to standards IEC 60947-4-1.
- IP 65 degree of protection.
- For supply voltages between 380 and 415 V. Control circuit is pre-wired between phases. For any other supply voltages, the control circuit must be wired by the customer.
- Overload relay must be ordered separately.
- Material: Polycarbonate.
