PowerLogic™ HDPM6000 I/O Module Installation Guide

The PowerLogic™ HDPM6000 I/O Module extends the HDPM6000 platform by providing two digital inputs, one analog input (0–10 VDC), one relay output, and one current transformer (CT) input. It supports integration with building management and DCIM systems through Modbus TCP/IP, SNMP, and BACnet/IP via the HDPM6000 head unit. The guide includes module dimensions, electrical and environmental specifications, mounting requirements, I/O terminal descriptions, CAT6 bus connection details, and instructions for CT installation, orientation, and wiring to ensure accurate measurement. The module is intended for applications such as data centers, industrial facilities, and infrastructure environments.
