Discover Acti9 Vigi NG125

Benefits of Acti9 Vigi NG125

Modularity & Cost saving

• Lower cost of installation due to cascading tables for NG125 MCB• Improved flexibility of rating selection vs RCBOs• On-product adjustable settings:- Tripping sensitivity from 30mA to 3A- Tripping time from instantaneous to selective and delayed
Easy Installation

• Foolproof design to ensure that the right Vigi add-on block is fitted with the right NG125 MCB• Plug-in system of QuickVigi that removes the need to screw at the terminals• Easy to remove from DIN rail without unwiring
Ease of operation

• Wide range of indicating and actuating auxiliaries for remote control and monitoring• Earth fault indication by LED on product front face or remotely• Pushbutton for disconnection to allow for dielectric test• Easy to remove from DIN rail without unwiring
Enhanced safety and Service Continuity

• Its Super Immune technology (-SI) associated with a protection class Type A will limit nuisance tripping and non-tripping in harsh electromagnetic conditions and polluted atmospheres• Pre-defined threshold of the alarm will monitor the earth leakage levels of your installation to prevent possible tripping thus improving the continuity of service

Features

Facts about Acti9 Vigi NG125

• Compliant with IEC/EN61009 • Voltage independent technology compliant with IEC/EN61009-2-1 • Available in 2P, 3P, and 4P up to 125A • Sensitivity (adjustable on a product): 30, 300, 1000, and 3000mA • Available in Type AC, Type A, and Type A-SI • Tripping time (adjustable on a product): instantaneous, selective (60ms), or delayed (150ms) • Insulation voltage (Ui): 690V • Pollution Degree: 3 • Rated impulse withstands voltage (Uimp): 8kV • Test button • Operating temperature: -5°C +60°C Type AC, -25°C +60°C Type A and A-SI • Wide range of tripping coil auxiliaries (MN, MNx, MX+OF) • Wide range of indicating auxiliaries (OF+OF, OF+SD) • SDV auxiliary for remote tripping indication • MXV auxiliary for remote tripping actuation • Wide range of accessories including rotative handles and terminal shields.
