NEX 24 | Schneider Electric Vietnam

Discover NEX 24

Benefits of NEX 24

Reliability

• The NEX 24 range has undergone type testing for each performance level.• NEX 24's development, production, and testing adhered to ISO 9001: 2000 quality standards.• Electrical fields examined using three-dimensional computer modeling methods.
Simplicity

• Intuitive user interface with operator error prevented by padlocks and interlocks.• Maintenance limited to simple routine operation.• Simple installation thanks to uniform civil engineering dimensions for all cubicles with possible installation against a wall.
Safety

• All operations, including access to connections and busbars performed from the front.• Power-on indicator located on the functional unit's front panel.• Earthing switch including a making capacity.• All NEX 24 operations use a single ''anti-reflex" handle.

Features

Facts about NEX 24

NEX 24 is manufactured, with our support, by franchised panel builders. NEX 24 includes a vacuum-type circuit breaker (Evolis range) and offers you: • Flexible and adapted solutions • Dedicated engineering • High mechanical and electrical endurance • A comprehensive range of performance levels • Enhanced operating safety • Environmental protection. Performances: • Technology: Vacuum • Standard: IEC • Rated voltage: 24 kV • Busbar system: Single • Rated operational current vacuum technology: 2000 A • Rated peak withstand current vacuum technology: 25 kA • Internal Arc Classification SF6 technology: AFLR 25 kA/1 s • Loss of service continuity: LSC 2B • Partition class: PM
