Discover TeSys K contactors

A full range of miniature contactors, up to 16 A for motor control (AC3/ AC3E) and 20A for resistive load control (AC1). Available as single contactors, star-delta, and reversing combos, with a wealth of options and accessories.

Benefits of TeSys K contactors

Compact size

Up to 50% less volume is captured in your panels
Flexibility

• Control voltages, consumption, noise levels • Power connections • Auxiliaries and accessories • Application-dedicated variants
Safety

• Ultimate protection by TeSys Deca circuit-breakers and TeSys LR2K thermal relays • NO or NC built-in auxiliary contact • IP20 finger-safe terminals • Suitable for safety applications, thanks to mirror contacts and mechanically linked auxiliary contacts (IEC 60947-4-1 and 60947-5-1 certified)

Features

Current ratings

• Up to 16 A in utilisation category AC3 / AC3E: Direct control motors, up to 7.5 kW (three-phase 400 V supplied) • Up to 20 A in utilisation category AC1: circuit and resistive load switching

Connection options

• Screw clamp • Spring terminals • Faston terminals • Solder pins for printed circuit boards (PCB)

Control options

• AC: 24 to 660/690 V, standard or low-noise versions • DC: 12 to 250V, standard or low consumption (1.8 W) versions • Additional electronic timers, suppressor modules, control relays, and thermal protection relays (LR2K) • Thermal protection relays

Auxiliary output contacts

• Built-in in all 3 pole versions: 1 NO or 1 NC • Up to 4 more by add-on blocks

Installation

Direct panel mounting or 35 mm DIN rail

Short-circuit protection

Type 1 coordination with TeSys Deca circuit-breakers

Standards and approvals

• IEC/EN 60947-4-1, IEC/EN 60947-5-1 • UL 60947-4-1, CSA C22.2 n° 60947-4-1, UL 60947-5-1 • CSA C22.2 n° 60947-5-1 • GB/T 14048.4 • NF C 63-110 • VDE 0660 • BS 5424 Certified by: CB Scheme, UL, CSA, CCC, EAC, EU, UKCA
