Discover EcoStruxure Power Automation System Engineering
Discover EcoStruxure Power Automation System Engineering
Standardised engineering software
Streamline your design, specification, and configuration of IEC 61850-compliant protection, automation, and control systems with EcoStruxure Power Automation System Engineering. This vendor-agnostic software standardises engineering workflows, reduces complexity, and enhances reliability for electrical substations – boosting efficiency, minimising errors, and ensuring adaptability for scalable, cost-effective system expansion.
Benefits of EcoStruxure Power Automation System Engineering
Benefits of EcoStruxure Power Automation System Engineering
Intuitive
Simplify standard compliance, reduce technical risks, and enhance quality with an intuitive graphical user interface, web-based documentation, video tutorials, and seamless virtual-to-real IED transformation.
Efficient
Reduce costs, delivery time, and technical risks through efficient top-down engineering. Minimise manual effort and errors with automated communication, HMI configuration, and template management.
Future proof
Designed for long-term adaptability, it evolves with your needs by focusing on system requirements instead of specific devices or vendors.
Features
Features
Smart system engineering
- Combines system specification and configuration tools to streamline workflows
- Supports IEC 61850 (Ed1, Ed2, Ed2.1) for compliance and interoperability
- Enables top-down/bottom-up engineering for diverse projects
- Maintains a single source of truth to simplify maintenance and upgrades
- Integrates IED tools via SCL to ensure consistent handover
- Models, applications, and coms to avoid toolchain fragmentation
Application standardisation
- Standardises IED models, HMI graphics, and naming to promote consistency
- Reuses templates across projects to reduce engineering time
- Enables multi-vendor integration to prevent vendor lock-in
- Supports Modbus and IEC 104 for broad protocol compatibility
- Builds bay templates to accelerate new deployments
- Separates function from device to simplify future upgrades
Automation and Productivity
- Auto-generates communication mapping and HMI to reduce configuration effort
- Detects repeated patterns to build templates faster
- Minimises manual tasks to cut engineering risk
- Produces SCD files to maintain system-level consistency
- Imports GOOSE/SV data via Excel to speed up bulk IED setup
- Enables faster FAT/SAT to shorten delivery timelines
