Discover Altivar 212
Discover Altivar 212
About Altivar 212
The Altivar 212 drive is designed for the most common fluid management applications (HVAC) in the service sector buildings, such as:• Ventilation• Heating and air conditioning• PumpingIts eco-energy design ensures a reduction in energy consumption of up to 70% compared to a conventional control system. Altivar 212 is operational from the moment the power is on; it can achieve maximum energy efficiency in your building.
Energy savings with a motor management solution
Motors are critical assets and big consumers of electrical energy, using 60% on average in industrial businesses. A robust, tested and validated architectural approach to your motor management unleashes more safety and performance for your motors, enabling advanced asset management and energy efficiency.With an extensive offer portfolio, competencies and know-how, we can help you build a sustainable motor integration solution across the electrical system and the industrial processes.
Benefits of Altivar 212
Benefits of Altivar 212
HVAC dedicated
Focused on Building Management Systems (BMS).
User-friendly
Easy set-up, commissioning and diagnostics tools.
Economical
Embedded functionalities and energy saving.
Protection & efficiency
Integrated EMC filter and anti-harmonic technology, BMS dedicated functions.
Features
Features
The Altivar 212 is a variable speed drive for 3-phase asynchronous motors from 0.75 kW to 75 kW. Specifically designed for the most common fluid management applications in tertiary sector buildings (HVAC) like heating, ventilation, air conditioning, and pumping. Energy savings of up to 70% can be achieved compared to a traditional control system, thanks to the eco-energy design.Altivar 212 covers motor powers between 0.75 kW and 75 kW on the following supplies:• 200…240V 3-phase, from 0.75 kW to 30 kW, IP 21• 380…480V 3-phase, from 0.75 kW to 75 kW, IP 21• 380…480V 3-phase, from 0.75 kW to 75 kW, UL Type 12/IP 55• Speed range: 1:50• Transient overtorque: 110% - 60 s.• Integrated EMC filters, categories C1 to C3 depending on model• Communication bus most commonly used on the market integrated: Modbus, METASYS N2®, APOGEE FLN P1®, and BACnet®. Optional: LonWorks• Complies to international standards and certifications: UL, CSA, C-Tick, and NOM• Anti-harmonic technology enables a THDI < 30% to be achieved
Centralised Technical Management• Instant viewing of the energy consumption• Detection of failures for quick intervention including belt breakage, pump running dry, phase failure, and supply fault• Preventative maintenance for reducing costs and optimising the equipment including fault alerts, operating times, and more• Connection to building supervision network using embedded protocolsUser-friendliness• Tools for installing, parameterising, and viewing the installation (remote graphic terminal in 6 languages, Multi-Loader, Bluetooth, and SoMove Mobile)• Compact size• Simple maintenanceProtection• Continuity of service assured• Dedicated “Building” series functions (fire mode, register monitoring, mechanical protection function, etc.)• Integrated EMC filter, anti-harmonic technology (THDI ˜ 30%)
Ventilation:• Less noise pollution (airdraulic noise, motor noise, etc.)• Detection of transmission component breakage• Smoke extraction: forced start with fault inhibition• Automatic restart• Allows register managementHeating and air conditioning:• Optimise control in fluid processing• Use of PID controller (temperature, flow rate, pressure, etc.)• Adjustable flow rates for better energy management• Suppression of mechanical resonance Pumping:• Detection of underload/overload, pump running dry• Multi-motor configuration• Limitation of operating time at low speed• Sleep/Wake function
Applications
Applications
Healthcare
Explore moreHotels
Explore moreFood and Beverage
Explore moreWater and Wastewater
Explore more
How-to videos
How-to videos
Programming Altivar 212 Drive for first time operation
Tutorial for initial configuration of the Altivar ATV212 Variable Frequency Drive (VFD) including all basic setup parameters for first-time use.
How to configure ATV212 for a fan application
Example of speed regulation or Flow regulation according to a reference.
Configuring preset speed operation on Altivar 212 Drives
Tutorial for adjusting low and high preset speed functionality on the Altivar ATV212 variable speed drive.
Programming an ATV212 Drive for 2 wire control & VIA as Speed Reference
Tutorial to programme the Altivar ATV212 drives for 2 wire control and to use a 0 to 10vdc speed signal on VIA.
