About Altivar Process ATV6000
The Medium Voltage Drive System with multi-pulse transformer and low voltage inverter cascade provides a sinusoidal sine wave at both input and output with low THD(I). The ATV6000 provides a high level of customisation to meet specific purposes, offering flexibility for modifications and extensions. Designed to ensure the continuity of your process and optimise maintenance costs, ATV6000 incorporates innovative power technology and advanced communication capabilities.
Continuous health monitoring with EcoStruxure Asset Advisor
Asset performance management services to enhance security, reduce downtime, and increase asset life and operation process efficiency. With additional EAA Sensors, the ATV6000 can monitor and provide condition base maintenance for • Environment conditions • Drive and application fault detection • MV Transformer ageing • Motor and load ageing • Cooling Fan failure
Energy Savings with Motor Management Solution
Motors are critical assets that consume a significant amount of electrical energy, accounting for roughly 60% of all electrical energy consumed in industrial businesses. A robust, tested and validated architectural approach to motor management unleashes more safety and performance for your motors, enabling advanced asset management and energy efficiency. With an extensive offer portfolio, competencies and know-how, we can help you build a sustainable motor integration solution across the electrical system and the industrial processes.
Benefits of Altivar Process ATV6000
Benefits of Altivar Process ATV6000
Process optimisation
Enhance equipment efficiency and reduce downtime up to 20% with a smarter operation connecting at every level with EcoStruture.
Energy risk management
Optimise and reduce your energy consumption by up to 30%. With sustainable energy efficiency without extra cost.
Tailored solution
High level of customisation to meet specific purposes, offering flexibility for modifications and extensions.
Services-orientated drives
Designed to ensure the continuity of your process and optimise maintenance costs.
Features
Features
• Input: 18-66 pulse diode rectifier bridge • Output: Multilevel PWM with low-voltage IGBT inverter cells • Power range: 160kW up to 20000 kW • Voltage Range: 2.4kV, 3.3 kV, 4.16 kV, 6.0 kV, 6.6 kV,10 kV,11 kV, 13.8kV • Motor type: Asynchronous motor, Synchronous motor, Permanent magnet motors • THDI: <3 % conforming to IEEE 519-1992 • Input power factor: ≥ 0.96 from 20% to 100% of load • Efficiency at rated power: Inverter efficiency is 98.5%. Drive efficiency including input transformer is 96% to 97% depending on the product.
ATV6000 medium voltage system delivers: • Tailored solutions to optimise your operational efficiency and investment • Optimised usage of energy and reduced consumption • Reduced downtime and improved uptime • Minimised Total Cost of Ownership & increase profitability • Improved productivity & availability
Services-orientated drives Improved operator efficiency with: • Easy access by QR code for online and remote support • Comfortable usability with the connected 10” Harmony HMI screen, also supported by storage oscilloscope function • Real-time intelligence enabled by native ethernet and embedded web server • Fast and easy on-site maintenance operation with Well-proven LV IGBT design • Modular architecture • Easy front access design With Digital services, ATV6000 manages the integrity of your equipment, your finances (OpEx and CapEx), and the performance of your production by: • Continuous monitoring of critical asset health and level of stress • 360° diagnostics on risk assessment, with report and analysis • Risk mitigation plan with anticipated actions to take • Access to 24/7 Schneider Electric service assistance Energy Management to help you optimise and reduce your energy consumption thanks to: • Embedded power management with <5% measurement accuracy • Best Efficiency Point function for pumps • Lifetime monitoring of energy usage and inbuilt energy dashboard • Phase shifted transformer for highly reduced THDI input on the grid • Integrated transformer with galvanic insulation feature • Low dV/dt inverter providing power without high over-voltage at the motor side Process Optimisation • Cellby pass feature • N+1 and N+2 power cell design for redundancy • Best Efficiency Point function for pumps • Solid and easily deployed Tested and validated applicative architecture (TVDA) • Fully compatibility with Schneider Electric EcoStruxure Process Automation Systems (hybrid & DCS systems) • Super sensor capabilities for predictive maintenance planning • Dedicated applicative control (droop control, fan/pump function, etc) Tailored Solution: • Application experts provide optimised engineering solutions for operational efficiency and investment optimisation. • Design process simplified and system implementation time is shortened • High level of customisation to fit purpose
Applications
Applications
Water and Waste Water
Explore moreMetals, Mining and Minerals
Explore moreOil and Gas
Explore morePower
Explore more
