Discover Acti9 iDPN Vigi

Acti9 iDPN Vigi is a residual current circuit breaker with overcurrent protection (RCBO) rated up to 40A protecting final distribution single-phase installations in commercial and industrial buildings. It complies with IEC/EN61009-2-1 standard to offer the following earth leakage protection functions: • Protection of people against electric shocks by direct contact (30mA) • Protection of people against electric shocks by indirect contact (300mA) • Protection of installations against risks of fire (300mA)

Benefits of Acti9 iDPN Vigi

  • Modularity and ease of installation

    • Tripping sensitivity from 30mA to 300mA to cover all earth leakage protection needs • Compatible with Acti9 9mm pitch comb busbar for power distribution

  • Ease of operation

    • Monitor and control Acti9 iDPN Vigi RCBO thanks to its wide range of indicating and actuating auxiliaries • Quickly identify the source of both earth leakage faults and overcurrent/short-circuit faults thanks to dual Visitrip mechanical flags on the product front face to reduce fault identification and repair • Carry out downstream maintenance safely with guaranteed contact opening thanks to the Vigisafe green strip on the Acti9 iDPN Vigi RCBO toggle • The top and bottom locking clips on the Acti9 iDPN Vigi RCBO make it simple to remove it from a DIN rail with a busbar in place

  • Enhance safety and continuity of service

    • Its super Immunised technology (-SI) together with a protection class Type A limit nuisance tripping and non-tripping in harsh electromagnetic conditions and polluted atmospheres • Front face class II insulation provides additional protection against electric shocks when operating the device

Features

Facts about Acti9 iDPN Vigi

• Compliant with IEC/EN61009 • Voltage-independent technology compliant with IEC/EN61009-2-1 • Available in 1PN from 4 to 40A • Sensitivity: 30, 100 and 300mA • Available in Type AC, Type A, and Type A-SI • Magnetic tripping curves: B and C • Breaking capacity (Icn): up to 10,000A • Limitation class: 3 • Insulation voltage (Ui): up to 400V • Pollution degree: 3 • Rated impulse withstand voltage (Uimp): 4kV • Test button • Operating temperature: -5°C +60°C Type AC, -25°C +60°C Type A and A-SI
