Discover ComPacT for DC Networks

Maximize power availability
In addition to significant design improvements, this new generation of ComPacT circuit breakers enhances power availability and reliability by:
Optimized selectivity and coordination with upstream and downstream Schneider Electric breakers.
Corrective, preventive, and predictive maintenance for asset management, thanks to advanced MicroLogic trip units.
Alerts as well as a local indication, with the new wireless auxiliary contact.
Efficiency
Transparent cover to quickly identify the auxiliaries.
QR code for easy access to all the documentation.
It integrates earth leakage protection and standardized accessories, allowing you to save space, time, and effort.
Reliability

Experience peace of mind with molded case circuit breakers optimized in size and featuring innovations tailored to your needs. Roto-active™ breaking technology helps to increase operation lifespan. You can rely on the ComPacT range, even in the most stressful of environments.
Connectivity

The new wireless auxiliary contact provides local and remote communication with trip alarms and pre-alarms, enabling increased proactive operational and energy efficiency.

ComPacT NSX DC - Circuit breakers for lines operating under 24 to 750 V DC:

1, 2, 3, and 4 poles up to 160 A
3 and 4 poles from 250 to 630 A
2 poles from 630 to 1200 A
Switch disconnectors: 16 A to 1500 A
4 Icu breaking capacity levels
F: 36 kA / 250 V DC (1 pole) or 500 V DC (2 poles in series) or 750 V DC (3 or 4 poles)
N: 50 kA / 250 V DC (1 pole) or 600 V DC (2 poles)
M : 85 kA / 250 V DC (1 pole) or 500 V DC (2 poles)
S: 100 kA / 500 V (2 poles) or 750 V (3 or 4 poles)
Accessories for insulation and series or parallel connection of poles, suited to the particularities of DC applications.
Fewer frame sizes: just two pole pitches (35 and 45 mm) for easy integration in installation systems (enclosures, machines, etc.).
Fixed and withdrawable versions (3 and 4 poles).
