Discover Power Supplies for industrial use, rail mounting

Benefits

Sustainable

Long life time and MTBF, conformal coating, operating temperature up to +70°C
Cost saving

Compact casing, NEC Class 2
Safe

Over and under voltage protection, Hazardous location certification
Easy to use

Wiring capabilities, multiple terminals, several mounting positions, wide input voltage range

Features

Modular ABLM

• From 10W up to 60W • Single and 2 phases 100…240VAC input • Modular housing with 18, 36, or 53mm width • NEC Class2 / LPS

Optimized ABLS

• From 50W up to 480W • Single and 2 phases 100…240VAC input • 2 housings formats for a better adaptation to the enclosure; compact and book • Conformal coating (optimized book) • NEC Class2 / LPS • Up to 6 output terminals make wiring easier

Universal 3 phases ABLU3

• From 240W up to 960W • 3 phases 380…500VAC input • One of the most compact power supplies on the market • Power boost (150% of the nominal power during 5 sec) • Conformal coating • 2 different output protection modes (Auto/Manu) • Diagnosis contact • Up to +70°C operating temperature • Compatibility with ABL8 functional modules

Universal 1/2 phases ABL8RP

• From 72W up to 480W • Single and 2 phases 100…500VAC input • Power boost (150% of the nominal power during 4 sec) • 2 different output protection modes (Auto/Manu) • Diagnosis contact • Compatibility with ABL8 functional modules

Functional modules ABL8

• Buffer module or Battery check modules and their batteries to ensure continuity of service in the event of a power outage • Redundancy module to meet the requirements for continuity of service even if the power supply is cut off • Downstream electronic Protection modules to make the protection in the application • Converter modules delivering nominal voltages of 5 and 12 VDC from the 24 VDC output of the Modicon Universal power supplies
