Discover Multi9
Discover Multi9
A comprehensive range for enhanced electrical threat protection
Fully compliant with all industry standards, Multi9 is ideally suited for all types of machine and equipment, providing you with protection and plenty of accessories and signaling functions.• All Multi9 DIN rail modular devices have been designed with performance in mind, ensuring you get enhanced protection.• Completely tailored for use by equipment manufacturers (OEMs), Multi9 meets every global standard for industry applications.• Wide selection of modular devices (MCB, RCD, SPD).• Provides protection, signaling functions, and accessories.• Compliant with UL489, UL1077, IEC, CCC, CSA standards, and more.
Benefits of Multi9
Benefits of Multi9
Easy to select
• Time-saving• Easy to procure and install• Meaningful commercial references
Multi-standard
• Multi9 covers all standards for Industry application: UL/CSA for North America, IEC, EAC, CC, and others for the rest of the world. It allows a unique panel design.
Sustainable
• 70% of the packaging is made with recycled cardboard• Green Premium products are RoHS and REACh compliant.
Wide range
• Wide range of solutions that are customized to fit your efficiency and sustainability needs
Features
Features
UL + IEC/EN 60947-2 + other standards:• C60BP – branch protection• C60BPR - branch protection with ring terminals• C60SP – supplementary protection• C60H-DC - supplementary protection dedicated to direct current.IEC/EN 60947-2:• C60N, C60H, and C60L (10 to 25 kA breaking capacity)• C60CTRL to protect the control circuit• N40N – 18mm phase and neutral MCB.
UL1053 + EN/IEC 61008-2-1:• GFP - Ground Fault ProtectorEN/IEC 61008-2-1:• Residual Current Circuit Breaker and Add-on residual current devices• RCCB ID - residual current circuit breakerEN/IEC 61008-2-1 + EN/IEC 62423:• RCCB-ID (B type) - residual current circuit breaker with direct current detectionEN/IEC 61009-2-1:• Vigi C60 – residual current device add-on for C60 MCB• Vigi N40 – residual current device add-on for N40N MCB• RCBO N40 Vigi - residual current circuit breaker with overcurrent protection.
UL 1449 4th Edition + CSA C22.2 Listed SPD Type 1 + IEC 61643-11• Multi9 PRD T1 75r - T1 Surge Protection Device
- Indication auxiliaries: OF, SD, OF/SD+OF
- For basic (from 100 mA to 6A) and advanced (from 2 mA to 100 mA) applications
- Compliant in harsh environment with low current auxiliaries
- Optimize your wiring (fewer wires and wiring time) inside a panel with the daisy chain architecture with low current auxiliaries. Monitoring up to 100 protective devices (permanently closed) under the daisy chain.
- Select the right offer:
- For basic applications, use the version from 100mA to 6A commercial reference M9A2690x.
- For low current application and daisy chain, use the commercial reference M9A2691x.
- Tripping auxiliaries: MN, MX
- instantaneous or delayed
- option: independent of the supply voltage
- Multi9 accessories
- Multi9 Comb busbars
- Linergy DS screw distribution blocks.
- PowerTag Energy
- Indication auxiliaries: OF, SD, OF/SD+OF
