Integrated temperature control in panel board

The TH-THP1+ range offers a selection of innovative DIN-rail mounted thermostats designed to increase user comfort and optimize energy consumption by controlling heating automatically:
- Temperature management provides significant energy savings and greater comfort.
- The choice of the operating mode: "reduced" or "above freezing" can be controlled by simple external switches.
Benefits of TH-THP1+
Benefits of TH-THP1+
Versatile sensor options
Wide temperature range
Programmable functionality
Features
Features
Facts about TH-THP1+
TH4 Thermostat
• Monitors and regulates ambient temperature from +8°C to +26°C
• Three operating modes:
-Comfort: Maintains desired temperature while premises are occupied
-Reduced: Allows user to pre-set temperature between 0°C to 10°C when premises are unoccupied
-Above Freezing: Fixed temperature setting of +5°C for prolonged non-occupancy periods
• Requires external on/off switch for "Reduced" and "Above Freezing" modes
• Delivered with an ambient probe
TH7 Thermostat
• Monitors and regulates temperature from -40°C to +80°C
• Ideal for frost protection solutions and applications requiring higher temperatures
• Equipped with different sensor options like floor probe, collar probe, outdoor probe, and ambient probe
THP1+ Thermostat
• Monitors and regulates ambient temperature from +10°C to +30°C
• Three operating Modes: Comfort, Reduced, and Frost Protection
• Offers weekly programmable features for home and tertiary use
• Controls single-zone heating and cooling
• Modes can be controlled with external switches or automatically based on user pre-defined values
• User settings are saved to internal memory (battery backup)
• Supports two different ambient probes: non-adjustable sensor (15835) and adjustable sensor (15836) - probes need to be ordered separately
