Discover EvoPact HVX Assembled Pole

The EvoPact HVX Assembled Pole 24 kV is designed with enhanced safety features. It can be configured for remote operation and remote racking, and it has strong interlocking and vacuum interrupters to deliver a superior experience. Suitable for many applications, including nuclear, marine, power generation, oil and gas, metals and mines, chemical industry, transportation, and utilities. EvoPact HVX is a fully type tested 24 kV Vacuum Circuit Breaker, ideal for applications requiring dependable performance.

Benefits

  • Compact design

  • Enhanced safety features

  • Dependable

Features

Facts about EvoPact HVX Assembled Pole

• Rated voltage 12 kV - 17.5 kV - 24 kV • Rated short circuit breaking current 25 kA - 31.5 kA - 40 kA - 50 kA • Rated short circuit duration 3s • Rated normal current 630 A - 1250 A - 1600 A - 2500 A - 3150 A - 4000 A - *5000 A* (*forced cooling in PIX-H) • No free-standing pole column • Vacuum interrupter chamber suspended free of external forces • Pole envelope with supporting and insulating functions • High mechanical protection thanks to pole envelope • Flexible application options:     • For fixed installation     • For mounting on isolating truck     • For drawer-type use

Applications

  • Oil and Gas

    Explore more

  • Mining, Minerals and Metals

    Explore more

  • Marine

    Explore more

  • Power Distribution

    Explore more

Panel Builders offers

Explore our panel builders offers to find the best option for building complete Medium Voltage switchgears and components and drive your business forward.
