Discover Altivar Process ATV6000

Benefits of Altivar Process ATV6000

Process optimization

Enhance equipment efficiency and reduce downtime up to 20% with a smarter operation connecting at every level with EcoStruture.
Energy management

Optimize and reduce your energy consumption by up to 30%. With sustainable energy efficiency without extra cost.
Tailored solution

High level of customization to meet specific purposes, offering flexibility for modifications and extensions.
Services-oriented drives

Designed to ensure the continuity of your process and optimize maintenance costs.

Features

• Input: 18-66 pulse diode rectifier bridge• Output: Multilevel PWM with low-voltage IGBT inverter cells• Power range: 160kW up to 20000 kW• Voltage Range: 2.4kV, 3.3 kV, 4.16 kV, 6.0 kV, 6.6 kV,10 kV,11 kV, 13.8kV• Motor type: Asynchronous motor, Synchronous motor, Permanent magnet motors• THDI: <3 % conforming to IEEE 519-1992• Input power factor: ≥ 0.96 from 20% to 100% of load• Efficiency at rated power: Inverter efficiency is 98.5%. Drive efficiency including input transformer is 96% to 97% depending on the product.
ATV6000 medium voltage system delivers:• Tailored solutions to optimize your operational efficiency and investment• Optimized usage of energy and reduced consumption• Reduced downtime and improved uptime• Minimized Total Cost of Ownership & increase profitability• Improved productivity & availability
Services-oriented drivesImproved operator efficiency with:• Easy access by QR code for online and remote support• Comfortable usability with the connected 10” Harmony HMI screen, also supported by storage oscilloscope function• Real-time intelligence enabled by native ethernet and embedded web server• Fast and easy on-site maintenance operation with Well-proven LV IGBT design• Modular architecture• Easy front access designWith EcoStruxure Asset Advisor combined with ATV6000, you can track the health and integrity of your equipment reducing OpEx expenses and improving the performance of your production by:• Continuous monitoring of critical asset health and level of stress• 360° diagnostics with report and analysis• Risk mitigation plan with recommended actions to take• Access to 24/7 Schneider Electric service assistanceEnergy Management to help you optimize and reduce your energy consumption thanks to:• Embedded power management +/- 5% measurement accuracy• Best Efficiency Point function for pumps• Lifetime monitoring of energy usage and inbuilt energy dashboard• Phase shifted transformer for highly reduced THDI input on the grid• Integrated transformer with galvanic insulation feature• Low dV/dt inverter providing power without high over-voltage at the motor sideProcess Optimization:• Cell bypass feature• N+1 and N+2 power cell design for redundancy• Best Efficiency Point function for pumps• Solid and easily deployed Tested and validated applicative architecture (TVDA)• Fully compatible with Schneider Electric EcoStruxure Process Automation Systems (hybrid & DCS systems)• Internal sensing and measurement of key VSD conditions for predictive maintenance planning• Dedicated application control (droop control, fan/pump function, etc)Tailored Solution:• Application experts provide optimized engineering solutions for operational efficiency and investment optimization.• Design process simplified and system implementation time is shortened • High level of customization to fit purpose
