Safety and reliability with Okken switchboards
Performance and efficiency
Functional applications for Okken switchboards
As part of the EcoStruxure™ Power platform, this tested and validated thermal monitoring solution detects overheating as a result of loose connections, unbalanced loads, and/or other issues inside an LV switchboard. This solution can run continuously (24/7), to complement or even replace the annual infrared inspection of your electrical system:
• Maintain operational uptime and business continuity
• Reduce operational expenses and total cost of ownership
• Protect building occupants and electrical distribution equipment
Power Control Center (PCC) features protection and power factor correction• Incomers: up to 6300 A (Masterpact circuit breakers)• Feeders: up to 6300 A (Masterpact circuit breakers), and 630 A (Compact circuit breakers)• Power factor correction: up to 540 kVAR
Motor Control Center (MCC) including protection, starters, and drives• Conventional starters up to 250 kW• Soft starters up to 250 kW• Drives up to 160 kW
iPMCC by Okken, intelligent switchboard solutions for energy efficiency• Smart advanced solution and smart devices for zero downtime tolerance, fault prevention, and automatic restarting• Better traceability with local or remote real-time access: status, measurements, diagnostics, trends, and energy consumption• Seamless integration with energy management and control systems (EMCS), and distributed control systems (DCS)• Tested, validated, and documented architectures (TVDA)• Industry-leading communication protocols
Optimized motor performance• Motor monitoring and failure protection in accordance with IEC/EN 60947-7-1• Motor synchronization and reduced peak consumption thanks to soft starters and variable speed drives• Reactive power compensation management and thermal monitoring to reduce costs and increase energy availability
Optimized footprint and modular design• Compactness and high stacking density• Single front or double front access thanks to back-to-back configuration• Top or bottom direct power connections, rear or side power connections• Fixed, disconnectable or withdrawable functional units
Withdrawable drawers optimization• Drawer size optimization: full and half-widths, heights from 100 to 600 mm• Direct connection to the arc-free vertical busbar (50 mm pitch)• Reliable drawer position indicator, and drawer stop
Stress-free upgrading, and maintenance• Upgrade energized equipment in complete safety thanks to the withdrawable drawers• Withdrawable Masterpact and plug-in Compact circuit breaker modules• Customer connection separate from the functional unit (form up to 4b)• Degree of protection up to IPxxD on busbars
To boost your return on investment and to be most efficient
Tools and support services• Advice and guidance for maintenance and upgrading• Regional and local services and support, assistance and troubleshooting• Customised vocational training, on site or in one of our training centers• Validated tools and architectures
Auditing, consulting, and solution engineering• Customised projects, including critical applications• Engineering expertise for new and existing sites• Installation and energy audits• Enterprise-wide energy efficiency solutions
Okken panel builder network• Manufacturing and delivery by the Schneider Electric Equipment Units or by licensed panelbuilders present all around the world• Licensed panelbuilders selected for their expertise, trained and regularly audited by Schneider Electric to guarantee top-quality equipment and support
Partner and discover digital toolsEcoStruxure Power Build is software for Okken low voltage switchboards – for easy configuration, quotation, and ordering available via our licensed partners’ program.
