- Watertightness: IP 66, NEMA 4-4X
- Polyurethane gasket put down on the lid.
- Double electrical insulation, Type II.
- Usage temperature: -25 up to +60°C
- Glow wire resistance: 650°C
- External mechanical resistance: IK 07,
- Rounded design intended to increase robustness.
- 20 dimensions from 74x74 to 341x291mm (exterior)
- 2 types of covers:
- Tinted transparent (from 138x93mm)
- Several heights for covers:
- Low covers: 10 and 20 mm
- High covers: 40, 60 and 80 mm
- 38 models in total.
- Equipment: Hinges, fixing lugs, cable entries, DIN rails, mounting plates, stand-offs and spacers, terminal boards, anti-condensation valve, coupling kit, shaped screws, quick opening handles.
- Look: Grey colour, RAL 7035.
- Certifications: TÜV, SEMKO, DEMKO.
