For ATV71**N4 range of drives, nominal output current at 415 volts can be derived using formula in below image
Within formula , i3 is the nominal current at 415V ,i1 is continuous output current value at 380 volts and i2 is continuous
output current value at 460 volts as described in catalog.
Within formula , i3 is the nominal current at 415V ,i1 is continuous output current value at 380 volts and i2 is continuous
output current value at 460 volts as described in catalog.
