Steps to import symbols from Ecostruxture Machine Expert Basic to GP-ProEx software are:
1. Create a symbol file and export it from Ecostruxture Machine Expert project.
2. Make modifications in the file as per the format of GP-ProEx.
3. Open GP-ProEx, then go to symbol variable under project window.
4. Click on utility and then import other formats to import the symbol list.
1. Create a symbol file and export it from Ecostruxture Machine Expert project.
2. Make modifications in the file as per the format of GP-ProEx.
3. Open GP-ProEx, then go to symbol variable under project window.
4. Click on utility and then import other formats to import the symbol list.
Released for:Schneider Electric India
