Question 1

Material Safety Data Sheets (MSDS) or Safety data Sheets (SDS) for Batteries Used in APC UPS 1 Phase Systems

Accepted Answer

Issue:I require the Material Safety Data Sheet (MSDS) or Safety Data Sheet (SDS) for various APC single phase UPS products.Product Line:All APC Single phase UPSEnvironment: All APC UPSCause: The majority of batteries used in APC by Schneider Electric Uninterruptible Power Supply (UPS) systems and Replacement Battery Cartridges (RBCs) are contained within cartridges and are sealed, non-spillable, maintenance-free lead acid batteries. The batteries are a manufactured article consisting of a plastic, sealed case, terminals and flame arrestor vent caps. Case color varies. The electrolyte is contained within the case and consists of the electrolyte held captive in an adsorbed glass mat (AGM) or gel matrix. There is no “free” electrolyte to leak out of the case. Under normal use and handling, there is no contact with the internal components of the battery or the chemical hazards. Under normal use and handling, these products do not emit regulated or hazardous substances. The design life of a sealed lead acid battery is 3-5 years depending on environmental factors. Using the batteries past the end of it’s design life can result in electrolyte leakage. In a few cases, Replacement Battery Cartridges (RBCs) containing High Power Lithium Ion Cell, Phosphate-Based are also used. These batteries are used stricitly in select models found in the Back-UPS Connect family. Resolution: North America UPS Battery MSDS Back UPS, Smart UPS, Easy UPS, Symmetra LX, Symmetra RMAll VRLA RBC, SYBT2, SYBT5Click Here Smart UPS Line Interactive Lithium Ion UPS Battery MSDS UN38.3 SCL500RM1NC / SCL500RM1UC / SCL500RM1UNCN/AClick HereClick HereSMTL750RM2UC / SMTL1000RM2UC / SMTL1500RM2UC N/AClick HereClick HereSMTL2200RMXXX / SMT2K2RMXXX / SMT3000RMXXX / SMT3KRMXXXAPCRBC174-LIClick HereClick Here Smart UPS Ultra UPS Battery MSDS UN38.3 SRTL2K2RM1UC / SRTL2K2RM1UNC / SRTL3KRM1UNC / SRTL3KRM1UWCAPCRBC173-LIClick HereClick HereSRTL50RMBP1U-LIN/AClick HereClick HereSmart UPS Ultra 5K-10K / SRTL180RM2UBP / Smart UPS Modular UltraSRYLBMClick HereClick Here Easy UPS Online Lithium Ion UPS Battery MSDS UN38.3 SRVSL1KRARK / SRVSL2K2RARK / SRVSL3KRARKRBCV181-LI / RBCV182-LI / RBCV183-LIClick HereClick HereSRVL48RMBP2U N/AClick HereClick HereSRVL48RMBP3UN/AClick HereClick Here Schneider Off-Grid UPS Battery MSDS UN38.3 PPS330N/AClick HereClick HerePPS500N/AClick HereClick HerePPS730N/AClick HereClick Here Microsoft Surface Hub 2S & Surface Hub 3 UPS Battery MSDS UN38.3 CSH2Click HereClick Here EU / International UPS Battery MSDS Back UPS, Smart UPS, Easy UPS, Symmetra LX, Symmetra RMAll VRLA RBC, SYBT2, SYBT5Click Here Smart UPS Line Interactive Lithium Ion UPS Battery MSDS UN38.3 SCL500RMI1UC / SCL500RMI1UNCN/AClick HereClick HereSMTL750RMI2UC / SMTL1000RMI2UC / SMTL1500RMI2UC N/AClick HereClick HereSMTL2200RMIXXX / SMT2K2RMIXXX / SMT3000RMIXXX / SMT3KRMIXXXAPCRBC174-LIClick HereClick Here Smart UPS Online Lithium Ion UPS Battery MSDS UN38.3 SRTL1000RMXLI / SRTL1500RMXLIXBP48RM1U-LIClick HereClick HereSRTL2200RMXLI / SRTL3000RMXLIXBP48RM1U2-LIClick HereClick HereSRTL1000RM4UXLI / SRTL1500RM4UXLI / SRTL2200RM4UXLI / SRTL3000RM4UXLIXBP48RM2U-LIClick HereClick Here Smart UPS Ultra UPS Battery MSDS UN38.3 SRTL2K2RM1UIC / SRTL2K2RM1UINC / SRTL3KRM1UINC / SRTL3KRM1UICAPCRBC173-LIClick HereClick HereSRTL50RMBP1U-LIN/AClick HereClick HereSmart UPS Ultra 5K-10K / SRTL180RM2UBP SRYLBMClick HereClick Here Easy UPS Online Lithium Ion UPS Battery MSDS UN38.3 SRVL1KRIRK / SRVSL1KRIRK / SRVL2K2RIRK / SRVSL2K2RIRK / SRVL3KRIRK / SRVSL3KRIRKRBCV181-LI / RBCV182-LI / RBCV183-LIClick HereClick HereSRVL48RMBP2UN/AClick HereClick HereSRVL48RMBP3UN/AClick HereClick Here Schneider Off-Grid UPS Battery MSDS UN38.3 PPS330N/AClick HereClick HerePPS500N/AClick HereClick HerePPS730N/AClick HereClick Here Microsoft Surface Hub 2S & Surface Hub 3 UPS Battery MSDS UN38.3 CSH2N/AClick HereClick Here APC Back UPS Connect UPS Battery MSDS UN38.3 CP12036LIN/AClick HereClick Here

Question 2

Replacing the Battery in a Smart-UPS

Accepted Answer

Issue: Smart-UPS requires battery replacement. Product line: Smart-UPS Environment: All models, all serial numbers. Cause: Smart-UPS batteries require replacement every 3-5 years. This document will assist you in replacing the battery. Resolution: Click Here to search by part number for the exact Smart-UPS unit you are using.On the product page of each Smart-UPS unit you will find a link to the user's manual on the "Documentation" tab. The manual for each unit will explain the battery replacement procedure.If your UPS is not listed your UPS may not have user replaceable batteries. Please contact our Customer Solutions Team for more information: https://www.se.com/ww/en/work/help/ Please refer to your users manual for the procedure for your specific model.

Question 3

How do I upgrade the firmware on an APC Network Management Card (NMC) or NMC embedded device?

Accepted Answer

Issue You wish to upgrade your Network Management Card's (NMC) firmware or have been instructed to.You have a device such as a Smart-UPS, Smart-UPS Ultra, Easy UPS On-Line, Easy UPS 3-Phase, Rack PDU, AV unit, or environmental monitoring unit with an embedded NMC that you wish to upgrade.You had a problem with a previous upgrade attempt and need the instructions in order to correct it.Your device came pre-loaded with the wrong application and you need to load the correct application. Product Line Network Management Card 2 - AP9630, AP9631, AP9635Network Management Card 3 - AP9640, AP9641, AP9643Network Management Card 3 for Easy UPS – AP9544, AP9547Network Management Card 4 – AP9644 Environment All serial numbersAll firmware versions (unless otherwise noted) CauseUsers may wish to upgrade their firmware to take advantage of enhancements, bug fixes, or new features. Also, sometimes a firmware upgrade can be interrupted or unsuccessful and these instructions can be followed to remedy the problem.Typically, these upgrades do not require the device the Network Management Card is installed in to be powered down or cause unnecessary downtime.Lastly, downgrades are not typically recommended but the manual methods can also be used to do those in certain circumstances.NOTE: To upgrade to firmware version 3.0 and higher for NMC3 for Smart-UPS, Easy UPS On-Line, and rPDU, the only supported method is the Secure NMC System (SNS) Tool, which requires a subscription to access the firmware. For more information, see www.se.com/secure-nmcResolutionFind Correct FirmwareWhen upgrading the firmware on your Network Management Card (NMC), you will need to determine which files pertain to your application. Begin by determining what model of NMC you have. AP9630, AP9631, AP9635 - Network Management Card 2AP9641, AP9641, AP9643 - Network Management Card 3AP9544, AP9547 - Network Management Card 3 for Easy UPS The application firmware required depends on what product your NMC is installed in. Some examples include: For NMC2 devices: SUMX for Smart-UPS 1-PhaseSY for Symmetra 1-Phase UPSSY3P for Symmetra 3-Phase UPS For NMC3 devices: SU for Smart-UPS 1-PhaseSY for Symmetra 1-Phase UPSSUCAN for Smart-UPS UltraRPDU2G for rPDU (Rack Power Distribution Unit)SY3P for Symmetra 3-Phase UPS For Easy UPS NMC devices: EU1P for Easy UPS 1-PhaseEU3P for Easy UPS 3-Phase NOTE: These instructions can also be used in devices that have embedded (mini) versions of the above Network Management Cards.NOTE: If you are interested in upgrading multiple devices at a time, refer to knowledge base FA156117 NOTE: If you have an AP9635 installed in a Symmetra PX 250/500, you have a Network Management Card 2 but MUST contact APC Technical Support in order to obtain the correct firmware and special instructions.Download Firmware Navigate to www.apc.com/secure-nmc and click the Software and Firmware tab.Find and download the latest firmware file for your NMC. NOTE: To upgrade to firmware version 3.0.0 and higher for NMC3 for Smart-UPS, Easy UPS On-Line, and rPDU, the only supported method is the Secure NMC System (SNS) Tool, which requires a subscription to access the firmware.Alternatively, visit https://www.apc.com/us/en/download/software-firmware/ and enter your NMC part number (e.g. AP9641), click the Firmware category, and download the latest firmware file. NOTE: Firmware updates of NMC3 or NMC4 for 3-Phase UPS and PDU can only be done by Schneider Electric qualified services representatives. Please contact your local Schneider Electric Service Representative or Schneider Electric Certified Service Partner for details. Update FirmwareThere are different ways that you can upload the firmware for each device. Please choose a method that works best for you. NOTE: For users upgrading (or downgrading) their Network Management Card 2 device from v5.X.X to v6.X.X, please review Knowledge Base article FA167693 to understand several important considerations prior to beginning any of these steps. Secure NMC System (SNS) Tool - Network Management Card 3 (for firmware versions 3.0 and higher)Universal Serial Bus (USB) 1.1 - Network Management Card 2 and 3 devices with a USB port (AP9631, AP9635, AP9641, AP9643 and RPDU devices (RPDU2G) and Smart-UPS Ultra devices with embedded NMC3 – for firmware versions 2.5 and lower)Firmware Upgrade/Update Utility - Network Management Card 2 and 3 (for NMC3 firmware versions 2.5 and lower)XMODEM - Network Management Card 2 and 3 (for NMC3 firmware versions 2.5 and lower)Manual (FTP prompt) - Network Management Card 2 and 3 (for NMC3 firmware versions 2.5 and lower)Manual - Secure CoPy (SCP) - Network Management Card 2 and 3 (for NMC3 firmware versions 2.5 and lower) Secure NMC System (SNS) Tool - Network Management Card 3 (firmware versions 3.0 and higher) Download the Secure NMC System (SNS) Tool from the APC/Schneider Electric website. As of SNS Tool v4.0, all units can be upgraded using the same program, excluding PDU's in an NPS setup. Part # (SKU) Secure NMC System (SNS) Tool SFNMC3FMTSU Secure NMC System Tool for Smart-UPS SFNMC3SUCAN Secure NMC System Tool for Smart-UPS Ultra SFNMC3RPDU Secure NMC System Tool for PDU SFNMC3FMTEU1PSecure NMC System Tool for Easy UPS On-Line NOTE: There are different versions of the SNS Tool depending on the application you are running on your NMC3. To access the firmware in the SNS Tool, you need a valid Secure NMC subscription. See www.apc.com/secure-nmc for more information. Double-click the self-extracting ZIP file. Add devices to the SNS Tool: To add one at a time: Click Add Devices and enter: the NMC’s IP address/FQDN/hostname the protocol and port to transfer the firmware file. SCP is recommended as it’s more secure than FTP. Note: The selected protocol must also be enabled on the NMC3. the user name and password To add more than one at a time: Open the devices.csv file in the downloaded SNS Tool directory and add the device details. Note: Lines that start with a semi-colon ; will not be processed. Save and close the devices.csv file. In the SNS Tool, click Add Devices. Click Import Device File – this button only appears if data is detected in the devices.csv file. Click Query Devices. Click Query Devices. Click Add Devices. Activate licenses for selected NMCs: Click on NMCs in the Device List and click License Devices. If you have more than 1 NMC in the Device List, use Ctrl+click to multi-select. Enter the Activation ID from the purchased Secure NMC System subscription and click Confirm & Activate. (If you have the SNS Tool installed on another PC and want to check if any of the NMCs are already licensed, you can click Sync License(s) to do so). Update firmware for selected NMCs: Click on NMCs in the Device List and click Update Firmware. If you click Update Firmware without selecting any NMCs from the Device List, the Firmware Management Tool will automatically select all of the NMCs that are eligible to update (Device Status = Ready for update). Universal Serial Bus (USB) 1.1 – Network Management Card 2* devices with USBNOTE: *If you have an AP9635 installed in a Symmetra PX 250/500, you have a Network Management Card 2 but MUST contact APC Technical Support in order to obtain the correct firmware and special instructions, PRIOR to following the steps below. Failure to do so may result in unexpected operation of your AP9635 Network Management Card 2. NOTE: Some USB flash drives are not compatible with the NMC2 devices. Secondly, the flash drive’s file system must be FAT, FAT16, or FAT32. (NTFS will not work).1. Obtain the latest firmware files from apc.com and extract them to a folder. Please note, USB may not allow for a firmware downgrade. You must use a manual method to accomplish a downgrade.2. Create a folder on your USB flash drive called apcfirm .3. From the latest firmware files that you downloaded, add to the apcfirm folder the binary files for the firmware modules that you would like to upgrade. Some examples of the binary files for the three firmware modules follow: Firmware ModuleBinary File APC Boot Monitor apc_hw05_bootmon_109.bin APC Operating System (AOS) apc_hw05_aos_712.bin Application Module apc_hw05_sumx_712.bin Language Pack* sumx_712_frFrdeDeruRuitItesEs.lpk *Optional language pack upgrades/changes are supported via USB if the device you’re upgrading already has BootMonitor v1.0.8 or higher (BootMonitor performs the upgrading function). NOTE: Not all NMC2 applications support language packs. 4. Use a text editor such as Microsoft Notepad to create a file called upload.rcf. NOTE: (Ensure that file extensions are visible so that your file does not get named upload.rcf.txt. In Windows, this option can be edited in Folder Options->View->Hide extensions for known file types within Control Panel. Make sure that option is unselected.) Add to the file a line for each firmware module that you want to upgrade as shown below (replace “xx” with the version of firmware you will be upgrading to): BM=apc_hw05_bootmon_xx.binAOS=apc_hw05_aos_xx.binAPP=apc_hw05_sumx_xx.binLANG=sumx_xx_frFrdeDeruRuitItesEs.lpk 5. Add the upload.rcf file to the apcfirm folder on the flash drive.6. Insert the flash drive into the USB port on the NMC2.7. Press and release the pinhole Reset button on the NMC2 for the USB upgrade process to begin. (This will only reboot the management interface of the NMC2 and not reboot your device/load.) The NMC2 status LED, located on the RJ-45 Ethernet jack, will begin to blink amber during this procedure and rotate through a few color flashing patterns while transferring the different files. NOTE: If you have an AP9631 or AP9635 removable NMC2 UPS SmartSlot card, you can also remove and re-insert the card into the UPS SmartSlot, effectively rebooting the NMC2 and beginning the USB upgrade process this way.8. Wait for 2-5 minutes for the upgrade to complete. Remove the flash drive from the USB port and check your firmware version. On a Rack PDU specifically, the LCD display will show the firmware version for three seconds and then will resume normal operation, at which time you can also remove the flash drive.Universal Serial Bus (USB) 1.1 – Network Management Card 3 devices with USB (firmware versions 2.5.0 and lower)This feature is available in bootloader version v1.3.3.1 and higher. Before starting the transfer, make sure the USB drive is formatted in FAT, FAT16 or FAT32. Download the firmware upgrade file.Create a folder named apcfirm on the USB flash drive.Place the .nmc3 file in the apcfirm directory.Use a text editor to create a file named nmc3.rcf. (The file extension must be .rcf, not .txt for example.)In nmc3.rcf, add a line for the firmware package to be upgraded. For example, to upgrade Smart-UPS application version v1.5.0.6, type: NMC3=apc_hw21_su_2-5-0-6.nmc3Place nmc3.rcf in the apcfirm folder on the flash drive.Insert the flash drive into a USB port on your NMCReboot the NMC and wait for the card to reboot fully. Firmware Upgrade/Update Utility – Network Management Card 2 and 3* (NMC3 firmware versions 2.5.0 and lower)If you have a Windows computer, you can use the Firmware Upgrade Utility (NMC2)/Firmware Update Utility (NMC3) to upgrade the firmware.If you have any other type of computer, then you will need to manually upload each firmware file to the Network Management Card. Go to the XMODEM or Manual sections below for additional instructions.NOTE: For any firmware downgrades, which are not typically recommended, you will need to choose a new method. The Wizard will block any downgrades. Unfortunately, loading applications for different devices may also have encounter this block if AOS versions are not the same.NOTE: *If you have an AP9635 installed in a Symmetra PX 250/500, you have a Network Management Card 2 but MUST contact APC Technical Support in order to obtain the correct firmware and special instructions, PRIOR to following the steps below. Failure to do so may result in unexpected operation of your AP9635 Network Management Card 2. Click on the firmware executable once the download is complete. The executable will proceed to unzip firmware files and extract them. You can specify the location where you want the firmware to download to.Once the firmware has been saved, the executable will prompt you for the IP address of the Network Management Card that you want to upgrade.Once you enter the IP address, click enter.You will be prompted for a username and password. This must be the Super User Account or an Administrator account. By default, the Super User username and password is apc. Press enter.If using the NMC2 Firmware Upgrade Utility, seen below, you will be prompted to enter the IP address and username and password. You can enter those and press Upgrade Now. If using the NMC3 Firmware Update Utility, seen below, you will be prompted to enter the IP address and username and password. You can enter those and press Start Update. The firmware executable will then begin the upgrade process. This process may take as long as 5-7 minutes to finish. Once finished, close the executable.Verify that the firmware upgrade was successful. Log into the Web UI and navigate to About -> Network. The updated firmware should be listed on this page. Alternatively, verify via Telnet, SSH, or local console connection on the main page after log in. XMODEM – Network Management Card 2 and 3 (for NMC3 firmware versions 2.5 or lower) Network Management Card 2 (AP9630, AP9631, AP9635)*NOTE: If you have an AP9635 installed in a Symmetra PX 250/500, you have a Network Management Card 2 but MUST contact APC Technical Support in order to obtain the correct firmware and special instructions, PRIOR to following the steps below. Failure to do so may result in unexpected operation of your AP9635 Network Management Card 2.NOTE: If you wish to downgrade from v6.X.X to v5.1.X firmware on NMC2, please make sure you review Knowledge Base Article FA167693 prior.1. Select a serial port at the local computer and disable any service that uses the port.2. Connect the provided serial configuration cable (APC part number 940-0299) to the selected 2.5mm Tip-Ring-Sleeve Console port on the Management Card itself. 3. Run a terminal program such as HyperTerminal, and configure the selected port for 57600 bps, 8 data bits, no parity, 1 stop bit, and no flow control. NOTE: certain terminal emulation programs, such as PuTTy, do not support the XMODEM protocol.4. Press the Reset button on the Management Card or reseat the Network Management Card in the SmartSlot, then immediately start pressing the key repeatedly until the Boot Monitor prompt displays: BM> . Also, once you have entered Boot Monitor mode correctly, the Network Management Card's status LED will flicker amber in color. (BootMonitor mode is required on NMC2 for an XMODEM upgrade in any situation.)5. Type XMODEM, then press ENTER. You will begin to see CCCCC scroll across the screen to indicate the Network Management Card is ready to receive a file.6. From the terminal program’s menu, select XMODEM, then select the binary bootmonitor firmware file to transfer using XMODEM. After the XMODEM transfer is complete, the Boot Monitor prompt returns.NOTE: If the boot monitor module must be updated, a boot monitor module is included in the firmware release. Otherwise, the boot monitor module that is installed on the card is compatible with the firmware update. If there is no included bootmonitor file, upgrade the AOS binary first.7. To install the application module, repeat step 5 and step 6. In step 6, use the application module file name.8. Type reset or press the Reset button to restart the Management Card.If the Management Card is installed in an Expansion Chassis or Triple Expansion Chassis, connect the provided configuration cable (APC part number 940-0299) to the serial port at the Management Card, or connect an RS-232 configuration cable (APC part number 940-0024) to the DB-9 serial port at the expansion chassis.If you connect an RS-232 configuration cable (APC part number 940-0024) to the DB-9 serial port of the expansion chassis, select 115200 bps.Network Management Card 3 (AP9640, AP9641, AP9643)1. Select a serial port at the local computer and disable any service that uses the port.2. To connect to a NMC3, use the provided micro-USB cable (APC part number 960-0603).3. Run a terminal program such as HyperTerminal, and configure the selected port for 57600 bps, 8 data bits, no parity, 1 stop bit, and no flow control. NOTE: Certain terminal emulation programs, such as PuTTy, do not support the XMODEM protocol.4. Press the Reset button on the Management Card or reseat the Network Management Card in the SmartSlot, then immediately start pressing the key repeatedly until the Boot Monitor prompt displays: BM>. Once you have entered Boot Monitor mode correctly, the Network Management Card 3's status LED will be solid orange in color. (Boot Monitor mode is required on NMC3 for an XMODEM upgrade in any situation.)5. Type XMODEM, then press ENTER. You will begin to see CCCCC scroll across the screen to indicate the Network Management Card is ready to receive a file.6. From the terminal program’s menu, select XMODEM and select the .nmc3 file to transfer. After the XMODEM transfer is complete, the Boot Monitor prompt returns.7. Type reset or press the Reset button to restart the Management Card.If the Management Card is installed in an Expansion Chassis or Triple Expansion Chassis, connect the provided configuration cable (APC part number 940-0299) to the serial port at the Management Card, or connect an RS-232 configuration cable (APC part number 940-0024) to the DB-9 serial port at the expansion chassis. If you connect an RS-232 configuration cable (APC part number 940-0024) to the DB-9 serial port of the expansion chassis, select 115200 bps. Manual (via FTP) - Network Management Card 2 and 3* (NMC3 firmware versions 2.5.0 and lower)Network Management Card 2NOTE: If you have an AP9635 installed in a Symmetra PX 250/500, you have a Network Management Card 2 but MUST contact APC Technical Support in order to obtain the correct firmware and special instructions, PRIOR to following the steps below. Failure to do so may result in unexpected operation of your AP9635 Network Management Card 2.1. To perform a firmware flash with this method the Management Card must have been previously configured with a System IP, Subnet Mask, and Default Gateway and attached to the network. In addition, FTP Server must be enabled.2. Open an MS-DOS command prompt window on a PC which is connected to the network. Change to the directory which contains the firmware upgrade files. Some example commands which need to be entered are shown in bold in order to change directories. Please note, this is just an example. You may need to enter a full path to a directory which requires different syntax.C:\> cd apcC:\apc> 3. Open an FTP client session.C:\apc> ftp 192.168.1.100 (192.168.1.100 being the IP address of the web card) 4. Log in. This must be the Super User Account or an Administrator account. By default, the Super User username and password is apc. Press enter.Typically, the password will appear on the screen as *** or not at all as you type. Connected to 192.168.1.100220- APC FTP server ready.User (192.168.1.100 :(none)): apc331 User name okay, need password.Password: apc230 User logged in, proceed.ftp> 5. Upgrade the bootmonitor file first. If the boot monitor module must be updated, a boot monitor module is included in the firmware release. Otherwise, the bootmonitor module that is installed on the card is compatible with the firmware update and can be skipped. If there is no included bootmonitor file, or you are using NMC1, upgrade the AOS first. The AOS module is the file with the AOS prefix. ftp> bin (specifies binary transfer mode which is required)200 Command okay.ftp> hash (optional - enables hash mark printing as a way of monitoring file transfer progress)ftp> put aosxx.bin (xx being the version number downloaded) Tip: With Windows Command Prompt in most OS versions, besides Vista, command prompt, you can drag and drop the file onto the command prompt window which will paste the full file path automatically here for you.200 Command okay.150 Opening data connection for aos301.bin###############################################################250 Requested file action okay, completed. Management Card Rebooting....327680 bytes sent in 5.99 seconds (54.70 Kbytes/sec)ftp> 6. Close the FTP client session to allow the card to continue rebooting as your FTP session will be disconnected and need to be re-opened for any further transfers. ftp>byeC:\apc> 7. Wait about 20 - 30 seconds.8. Repeat Steps 3 - 8 again for the application module (sumx for Smart UPS/Matrix, sy for Symmetra, etc). In Step 6, substitute the sumx module file name, in place of the AOS module file name. Or the sy prefix for the Symmetra. NOTE: To upgrade multiple Management Cards using an FTP client or using SCP, write a script which automatically performs the procedure.NOTE: If using MacOSX, the full filepath of the destination folder will need to be included in the "put" command. An example command would read:ftp> put /Users/Admin/Downloads/aosxx.bin /aosxx.binNetwork Management Card 31. To perform a firmware flash with this method the Management Card must have been previously configured with a System IP, Subnet Mask, and Default Gateway and attached to the network. In addition, FTP Server must be enabled.2. Open an MS-DOS command prompt window on a PC which is connected to the network. Change to the directory which contains the firmware upgrade files. Some example commands which need to be entered are shown in bold in order to change directories. Please note, this is just an example. You may need to enter a full path to a directory which requires different syntax.C:\> cd apcC:\apc>3. Open an FTP client session.C:\apc> ftp 192.168.1.100 (192.168.1.100 being the IP address of the web card) 4. Log in as Administrator (apc is the default user name and password). 5. Upgrade the firmware:ftp> bin (specifies binary transfer mode which is required)ftp> hash (optional - enables hash mark printing as a way of monitoring file transfer progress)ftp> put apc_hw21_SU_xx.nmc3 (xx being the version number downloaded)6. When FTP confirms the transfer, type quit to close the session. 7. Wait about 20 - 30 seconds. NOTE: To upgrade multiple Management Cards using an FTP client or using SCP, write a script which automatically performs the procedure.Manual (via Secure CoPy) - Network Management Card 2 and 3* (NMC3 firmware versions 2.5.0 and lower)Network Management Card 2NOTE: If you have an AP9635 installed in a Symmetra PX 250/500, you have a Network Management Card 2 but MUST contact APC Technical Support in order to obtain the correct firmware and special instructions, PRIOR to following the steps below. Failure to do so may result in unexpected operation of your AP9635 Network Management Card 2.NOTE: If you wish to downgrade from v6.X.X to v5.1.X firmware on NMC2, please make sure you review Knowledge Base Article FA167693 prior.1. Identify and locate the firmware modules described in the preceding instructions for FTP.2. Use an SCP command line to transfer the AOS firmware module to the Management Card. The following example uses xx to represent the version number of the AOS module: scp apc_hw05_aos_xx.bin apc@158.205.6.185:apc_hw05_aos_xx.bin 3. Use a similar SCP command line, with the name of the application module, to transfer the application firmware module to the Management Card. NOTE: To upgrade multiple Management Cards using an FTP client or using SCP, write a script which automatically performs the procedure. Alternatively, you can use APC's INI utility which is downloadable and explained in Knowledge Base Article FA156117.NOTE: Never remove a Management Card before it completes the reboot cycle. Doing so will damage the Management Card. The reboot cycle is complete when the status LED turns off and after 20 seconds turns solid green or slowly flashing Network Management Card 3Use an SCP command line to transfer the .nmc3 file to the Management Card. The following example uses xx to represent the version number of the application module: scp apc_hw21_SU_xx.nmc3 apc@158.205.6.185:apc_hw21_SU_xx.nmc3 NOTE: To upgrade multiple Management Cards using an FTP client or using SCP, write a script which automatically performs the procedure. Alternatively, you can use APC's INI utility which is downloadable and explained in Knowledge Base article FA156117.NOTE: Never remove a Management Card before it completes the reboot cycle. Doing so will damage the Management Card. The reboot cycle is complete when the status LED turns off and after 20 seconds turns solid green or slowly flashing amber.

Question 4

What is the expected life of my APC UPS VRLA battery?

Accepted Answer

Issue:What is the expected life of my APC UPS VRLA Battery?Product Line:All UPS ModelsEnvironment: All Three Phase and Single Phase UPS Models Cause / Resolution:Most APC batteries should last three to five years. There are many factors which affect Battery life including environment and number of discharges. Below are some guidelines to ensure optimum life expectancy: 1. Operating Temperature: The optimal operating temperature for a lead‑acid battery is 20–25°C (68–77°F). Operating at higher temperatures significantly reduces battery lifespan. As a general rule, every 8°C (15°F) increase in temperature will cut the battery’s life in half. For example, a battery expected to last 4 years at 25°C (77°F) would only last about 2 years if operated at 33°C (95°F). Keep in mind that the internal battery temperature of a UPS is always higher than the ambient room temperature. Because of this, it is strongly recommended to install the UPS in a location with good airflow, proper ventilation, and adequate cooling to help maximize battery life. 2. Battery Calibration and Deep Discharge: You should perform runtime calibrations on your UPS only once or twice per year, and only if truly necessary. While some customers run calibrations to verify that their available runtime is sufficient, performing these tests too frequently can significantly shorten the lifespan of the APC battery. It is also important to remember that a UPS is not designed for frequent deep‑discharge cycles. We do not recommend using an APC Smart‑UPS or Back‑UPS as a portable power source that is repeatedly discharged and recharged (for example, when mounted on a mobile equipment cart). These units are specifically engineered for emergency backup power during unexpected outages or brief power interruptions—not for continuous cycling like a portable battery pack. 3. Storage: APC batteries should not be stored for extended periods of time. New batteries or UPS units should be stored for no longer than 6 months from the date of purchase, as they leave the factory at approximately 80% charge. After this period, the battery should be placed into use; otherwise, it will lose a significant portion of its charge. It is also not recommended to store batteries that have already been in use. Long‑term storage without periodic recharging can lead to reduced lifespan and unpredictable performance. Temperature and Storage Recommendations Storage temperature has a major impact on how quickly a battery degrades while not in use: –15°C to +30°C (5°F to 86°F):Perform a full recharge cycle at least every 6 months. +30°C to +45°C (86°F to 113°F):Perform a full recharge cycle at least every 3 months. Proper storage temperature and periodic recharging are essential to preserving battery health and ensuring reliable performance when the UPS is finally placed into service. 4. Load: As the load on your UPS increases, the available runtime decreases. For best performance and battery longevity, it is recommended not to exceed 80% of the UPS’s rated capacity. If a power outage occurs while the UPS is operating at or near full load, the battery will discharge much more quickly, reducing the amount of backup time available. Frequent heavy loads and rapid discharges can also significantly shorten the battery’s overall life expectancy. 5. Battery chemical reaction: As a VRLA (AGM) battery ages, it undergoes a chemical process known as sulfation. This occurs when lead sulfate crystals harden on the battery plates, reducing the battery’s ability to charge and discharge efficiently. This can lead to several noticeable effects: Longer charging times than normalExcessive heat buildup, which can eventually cause electrolyte “boil‑out”Shorter runtimes between chargesSignificantly reduced overall battery life 6. Battery replacement: Since the typical end‑of‑life for VRLA batteries is approximately five (5) years, it is strongly recommended to replace the UPS battery before reaching this age. Doing so helps prevent performance degradation and reduces the risk of possible hydrogen sulfide gas emission, which can occur when aging batteries begin to fail. 7. Firmware Improvements: For selected single‑phase Smart‑UPS models, it is recommended to update the UPS firmware to the latest available version. This ensures the unit benefits from all battery‑related enhancements, stability improvements, and performance optimizations provided by APC. For instructions and compatibility details, refer to FA164737, which outlines the process for updating firmware on supported single‑phase Smart‑UPS units. If you have any clarifications, please feel free to contact us at 1-800-800-4272 or chat with our technical support representatives.

Question 5

How to Upgrade Firmware on Smart-UPS Models Using the Firmware Upgrade Wizard

Accepted Answer

Introduction: Most Smart-UPS models support user-upgradeable firmware. Firmware upgrades can provide product improvements, feature enhancements, and cybersecurity remediations throughout the product lifecycle. Important: During a firmware upgrade, battery backup is unavailable. Equipment powered by the UPS will not be protected from power failures. Depending on the UPS model, UPS output power may need to be turned off before the firmware can be upgraded. The Firmware Upgrade Wizard will advise you on how to proceed.Certain UPS models do not support firmware upgrade using a USB connection. To upgrade the firmware of these UPS units using the Firmware Upgrade Wizard, a local connection via serial cable must be used. The serial cable supplied with the UPS must be used.Ensure the computer remains powered on and the communication connection between the UPS and the computer is maintained throughout the firmware upgrade process.Schneider Electric recommends upgrading Smart-UPS On-Line SRT, XP, and XU firmware only when instructed by Schneider Electric Technical Support or when advised through an official Schneider Electric communication. To view different UPS firmware upgrade methods, refer to FA164737. Applicable models: Click to expand and view details The following UPS model families support user-upgradeable firmware using the Firmware Upgrade Wizard. Supported UPS model families CSHSCLSMCSMTSMTLSMXSRTSRTLXPXU As support for additional UPS models is added over time, the list below identifies UPS models that are not currently supported by the Firmware Upgrade Wizard. UPS models that do not support user-upgradeable firmware using the Firmware Upgrade Wizard Smart-UPS Ultra 5, 8, and 10kVA modelsSmart-UPS Ultra Modular models with the prefix SRYLUPS models with the prefixes SU, SUA, SUM, SURT, SURTA, and SURTDSMX750, SMX1000, and SMX1500 UPS models with ID 11 running UPS firmware version 02.x or earlierDevices not supported in the current release: SMT750RMJ1U, SMT2200, SMC2200XLI-BR Firmware Upgrade: The Firmware Upgrade Wizard automatically identifies the connected UPS and selects the appropriate firmware file. Note: Downgrading firmware to an earlier version is not recommended. Important: Do not disconnect the UPS communication cable, reboot the computer, or attempt to turn off the UPS during the firmware upgrade.If a previous version of the Firmware Upgrade Wizard is installed, uninstall it before downloading the latest version. Step 1 Download the latest version of the Firmware Upgrade Wizard ZIP file, and the Firmware Upgrade Wizard User Guide. Step 2 Important: Verify the MD5 checksum of the downloaded Firmware Upgrade Wizard ZIP file. The current MD5 checksum is 47c9f0ebc3482359d16c0ebc1798eae9. Open Command Prompt.Change the directory to the folder where the downloaded Smart-UPS_Firmware_Upgrade_Wizard_v4.3.8v12a.zip was saved: This is typically done using the "cd" command.For example, if the Smart-UPS_Firmware_Upgrade_Wizard_v4.3.8v12a.zip file was saved to the Downloads folder, the command may be: "cd C:\Users\Username\Downloads", or "cd Downloads" Run the command "certutil -hashfile Smart-UPS_Firmware_Upgrade_Wizard_v4.3.8v12a.zip MD5"Verify that the displayed MD5 checksum exactly matches the value shown above.For example: Step 3 The Firmware Upgrade Wizard ZIP file contains the application and all required UPS firmware files. The accompanying User Guide provides detailed prerequisites, instructions, and screenshots. Follow the Firmware Upgrade User Guide to update the firmware of your UPS. Depending on the UPS model and upgrade path, the firmware upgrade process may take approximately 25 to 30 minutes. If the firmware upgrade does not complete, contact Schneider Electric Technical Support. Provide the UPS model, serial number, UPS ID, and current firmware revision.

Question 6

Warranty Support and Verification

Accepted Answer

I have a 1PH APC Product. What is your warranty policy? Product Line APC equipment purchased from qualified and legitimate resellers and/or distributors. Resolution At APC by Schneider Electric, we value your business and are committed to ensuring your devices are properly registered and supported. To verify your unit’s warranty status or correct any details, please use our online services:🔗 Check Warranty Status Warranty Policy References For your convenience, warranty policies are outlined in the following resources: APC Back-UPS™ and APC Portable Power Station (Schneider OffGrid):🔗 View FAQ APC Smart-UPS™:🔗 View FAQ APC Rack PDU, Rack ATS, and SmartSlot™ Cards:🔗 View FAQ APC Symmetra LX and RM™, including compatible replaceable modules:🔗 View FAQ Warranty Discrepancies and Support In rare cases, warranty records may not reflect the actual purchase date. If you notice any discrepancies or would like to confirm or correct your warranty details, please contact us: 📞 Phone: 1-800-800-4272💬 Live Chat: Chat with Technical Support Please have the following information ready: Model or SKU numberSerial Number (SN) of the device or accessory Note: The location of the serial number may vary depending on the model. Our support team can assist you in locating it. Warranty Disclaimer Schneider Electric reserves the right to refuse warranty correction for any unit or device not purchased through authorized resellers or legitimate distributors. To ensure eligibility for warranty support, customers may be required to present proof of purchase from a recognized sales channel. For a list of authorized resellers and distributors, please visit: 🔗 Schneider Electric Partner Locator

Question 7

How do I update the firmware of my CSH, SCL, SMC, SMT, SMTL, SMX, SRT, SRTL, SRYL, XP, and XU series Smart-UPS?

Accepted Answer

Issue: Most Smart-UPS products feature user updateable UPS Firmware.This allows for ongoing improvements, feature enhancements, and cybersecurity remediations of Smart-UPS products after deployment.Product line: CSH, SCL, SMC, SMT, SMTL, SMX, SRT, SRTL, SRYL, XP, and XU series Smart-UPSEnvironment:Since we will continually release new products that are supported by the tool, we identify devices that are NOT supported.Devices that do NOT have updateable firmware: UPS Models with the prefixes SRC, SU, SUA, SUM, SURT, SURTA, SURTDSMX750, SMX1000, SMX1500 with ID 11 and firmware UPS 02.x or lower. These units are 120 V devices built prior to date code 1037. Date code is the first 4 numbers in your serial number. (e.g. Serial Number AS1036123456 would not be supported.) Resolution:There are several methods to update the firmware of the UPS:Locally via a Serial connection using the Firmware Upgrade Wizard application. This is the most universal method and should be used whenever possible. CLICK HERE to update using a Serial connection and the Firmware Upgrade Wizard. (RECOMMENDED) Remotely via the web interface of the Network Management Card (NMC): requires a a SmartSlot or Embedded NMC. CLICK HERE to update using the web interface of the Network Management Card Remotely via the command line interface of the Network Management Card (NMC): requires a a SmartSlot or Embedded NMC.CLICK HERE to update using the command line interface of the Network Management Card Remotely via SmartConnect - supported only by EcoStruxure Ready Smart-UPS devices only (UPS Models with the prefixes SCL, SMC, SMT, SMTL, SMX, SRTL models with a "C" suffix; e.g. SMX1500IC, SCL500RMI2UC, SMT1500C, SMX1000C). CLICK HERE to update via Smart-Connect Locally via a USB flash drive - supported by XU1K3LLXXRCC and certain Smart-UPS SRT and SRTL UPS models only. CLICK HERE to update via a USB flash drive The Firmware Upgrade Wizard, Network Management Card, SmartConnect and USB methods may require that the UPS output power is turned off. If the UPS output power must be turned off, ensure that your network access is not dependent on the UPS for power when updating via the Network Management Card or SmartConnect.

Question 8

Is it ok to turn off my UPS when not in use?

Accepted Answer

Question:Is it ok to turn off my UPS when not in use? Scenario:APC by Schneider Electric notes that this question is often asked by our customers who would want to make sure there are no electronics that are on while they leave their homes or their place of work/business. It can also apply to times of expected power outages or electrical testing to be done at their areas.Product Line:All 1PH APC by Schneider Electric UPS units - All INDOOR - Plugged in models - All Serial NumbersResolution: As long as the UPS is getting adequate power or it is plugged in to a good power source, then it will be ok. If this is something we cannot avoid then please keep the following bullet points in mind. Make sure all batteries are disconnected from the UPS before unplugging them.Make certain we always recall FAQ FA156516. Although this FAQ does state that the minimum is 3 months (as per environmental conditions). APC by Schneider Electric deeply advises that this is NEVER done repeatedly as this can lead to batteries dying earlier than expected. Failure to follow the mentioned FAQ may cause the batteries to discharge completely and can result to them failing prematurely. Portable Power Stations (PPS330, PPS500, PPS730) are designed to hold a charge for prolonged periods of time. Please refer to FAQ000271771 for the discharge rates of these offers. They will only use their port power only if they are on and with a load being fed. If you have any clarifications, please feel free to contact us at 1-800-800-4272 or chat with our technical support representatives.

Question 9

What is the selection criterion of Circuit Breakers for the Capacitor bank application.

Accepted Answer

The selection should be done after derating the Circuit Breaker taking into consideration voltage variation and capacitors tolerances that could increase nominal current up to 1.5In. The Derating factor of 1.5In Where In = Q/ ( Square root of 3 ) Un Q = Capacitor Power Un = Nominal Voltage Choose the Micrologic with delay time selection, so that the Circuit Breaker does not trip due to initial high inrush current. Also to be taken into account are the parameters like supply frequency, operating voltage & harmonics level of the power system for such application. Refer the attached sheet for further details for selection of Circuit Breaker for Capacitor duty application. Note: Use the phase barrier between the phases in Circuit Breaker to prevent flashover due to heavy inrush current.

Question 10

Why is Neutral and Earth (Ground) Connection forbidden Downstream from Main Panel?

Accepted Answer

The question is often asked what is the maximum voltage permitted between the Neutral and Earth (Ground) conductor and if the Neutral and Earth can be bridged to achieve a zero value.This can be a difficult topic, in fact in many cases it can be dangerous. As you will see from the attached document, there are many reasons why it is not allowed.
