Question 1

What is the difference between the iC65 and the iC60 circuit breakers?

Accepted Answer

The Acti9 iC65 range of circuit breakers have the same external dimensions as the iC60 range but are not approved for use or sale in Australia. Only the Acti9 iC60 range of miniature circuit breakers and residual current devices as listed in the Schneider Electric Australia catalogue and website are approved and marked to show compliance with Australian regulations.http://www.schneider-electric.com.au/en/search/iC60?category=all

Question 2

What is the code for a 32A Type B RCBO for EV chargers?

Accepted Answer

We do not have any Type B RCBOs available, but this protection can be achieved using a RCCB and MCB.Single phase = A9Z51240 + A9F542323 phase = A9Z51440 + A9F54432

Question 3

What is Modbus and How does it work?

Accepted Answer

What is Modbus? Modbus is a serial communication protocol developed by Modicon published by Modicon® in 1979 for use with its programmable logic controllers (PLCs). In simple terms, it is a method used for transmitting information over serial lines between electronic devices. The device requesting the information is called the Modbus Client and the devices supplying information are Modbus Servers. In a standard Modbus network, there is one Client and up to 247 Servers, each with a unique Server Address from 1 to 247. The Client can also write information to the Servers.The official Modbus specification can be found at https://modbus.org/ What is it used for? Modbus is an open protocol, meaning that it's free for manufacturers to build into their equipment without having to pay royalties. It has become a standard communications protocol in industry, and is now the most commonly available means of connecting industrial electronic devices. It is used widely by many manufacturers throughout many industries. Modbus is typically used to transmit signals from instrumentation and control devices back to a main controller or data gathering system, for example a system that measures temperature and humidity and communicates the results to a computer. Modbus is often used to connect a supervisory computer with a remote terminal unit (RTU) in supervisory control and data acquisition (SCADA) systems. Versions of the Modbus protocol exist for serial lines (Modbus RTU and Modbus ASCII) and for Ethernet (Modbus TCP). How does it work? Modbus is transmitted over serial lines between devices. The simplest setup would be a single serial cable connecting the serial ports on two devices, a Client and a Server. The data is sent as series of ones and zeroes called bits. Each bit is sent as a voltage. Zeroes are sent as positive voltages and a ones as negative. The bits are sent very quickly. A typical transmission speed is 9600 baud (bits per second). What is hexadecimal? When troubleshooting problems, it can be helpful to see the actual raw data being transmitted. Long strings of ones and zeroes are difficult to read, so the bits are combined and shown in hexadecimal. Each block of 4 bits is represented by one of the sixteen characters from 0 to F. Each block of 8 bits (called a byte) is represented by one of the 256 character pairs from 00 to FF. How is data stored in Standard Modbus? Information is stored in the Server device in four different tables. Two tables store on/off discrete values (coils) and two store numerical values (registers). The coils and registers each have a read-only table and read-write table. Each table has 9999 values. Each coil or contact is 1 bit and assigned a data address between 0000 and 270E. Each register is 1 word = 16 bits = 2 bytes and also has data address between 0000 and 270E. Coil/Register Numbers can be thought of as location names since they do not appear in the actual messages. The Data Addresses are used in the messages. For example, the first Holding Register, number 40001, has the Data Address 0000. The difference between these two values is the offset. Each table has a different offset. 1, 10001, 30001 and 40001. What is the Server ID? Each server in a network is assigned a unique unit address from 1 to 247. When the client requests data, the first byte it sends is the Server address. This way each server knows after the first byte whether or not to ignore the message. What is a function code? The second byte sent by the Client is the Function code. This number tells the server which table to access and whether to read from or write to the table. What is a CRC? CRC stands for Cyclic Redundancy check. It is two bytes added to the end of every modbus message for error detection. Every byte in the message is used to calculate the CRC. The receiving device also calculates the CRC and compares it to the CRC from the sending device. If even one bit in the message is received incorrectly, the CRCs will be different and an error will result. . What are the formats of Modbus commands and responses? What are data types? The example for FC03 shows that register 40108 contains AE41 which converts to the 16 bits 1010 1110 0100 0001 Great! But what does it mean? Well, it could mean a few things. Register 40108 could be defined as any of these 16-bit data types: A 16-bit unsigned integer (a whole number between 0 and 65535) register 40108 contains AE41 = 44,609 (hex to decimal conversion) A 16-bit signed integer (a whole number between -32768 and 32767) AE41 = -20,927 (hex to decimal conversion that wraps, if its over 32767 then subtract 65536) A two character ASCII string (2 typed letters) AE41 = ® A A discrete on/off value (this works the same as 16-bit integers with a value of 0 or 1. The hex data would be 0000 or 0001) Register 40108 could also be combined with40109 to form any of these 32-bit data types: A 32-bit unsigned integer (a number between 0 and 4,294,967,295) 40108,40109 = AE41 5652 = 2,923,517,522 A 32-bit signed integer (a number between -2,147,483,648 and 2,147,483,647) AE41 5652 = -1,371,449,774 A 32-bit double precision IEEE floating point number. This is a mathematical formula that allows any real number (a number with decimal points) to represented by 32 bits with an accuracy of about seven digits. AE41 5652 = -4.395978 E-11 Here is a spreadsheet IEEE float calculator for inputs of 4 bytes or 2 words. To download a copy, right click and select Save Target As... A four character ASCII string (4 typed letters) AE41 5652 = ® A V R More registers can be combined to form longer ASCII strings. Each register being used to store two ASCII characters (two bytes). What is byte and word ordering? The Modbus specification doesn't define exactly how the data is stored in the registers. Therefore, some manufacturers implemented modbus in their equipment to store and transmit the higher byte first followed by the lower byte. (AE before 41). Alternatively, others store and transmit the lower byte first (41 before AE). Similarly, when registers are combined to represent 32-bit data types, Some devices store the higher 16 bits (high word) in the first register and the remaining low word in the second (AE41 before 5652) while others do the opposite (5652 before AE41) It doesn't matter which order the bytes or words are sent in, as long as the receiving device knows which way to expect it. For example, if the number 29,235,175,522 was to be sent as a 32 bit unsigned integer, it could be arranged any of these four ways. AE41 5652 high byte first high word first 5652 AE41 high byte first low word first 41AE 5256 low byte first high word first 5256 41AE low byte first low word first What is a Modbus Map? A modbus map is simply a list for an individual server device that defines - what the data is (eg. pressure or temperature readings) - where the data is stored (which tables and data addresses) - how the data is stored (data types, byte and word ordering) Some devices are built with a fixed map that is defined by the manufacturer. While other devices allow the operator to configure or program a custom map to fit their needs. What is the difference between Modbus ASCII and Modbus RTU? Modbus RTU and Modbus ASCII talk the same protocol. The only difference is that the bytes being transmitted over the wire are presented as binary with RTU and as readable ASCII with Modbus RTU. important to note about RTU is that the RTU message does not have a Start_of_text indication. The receiving party in the communications uses a "silent" time in order to determine the start of a new message. ASCII does have a start-of-text token. Binary messages are shorter than ASCII and therefore theoretically faster to transmit/receive. You may be happy to see update rates of about 100 ms in your HMI/SCADA and could choose either communication.Summary:- use RTU is possible- use ASCII in case RTU is giving timeout problems on WinNT or when using slow communications media like 300 bps or dialup modems Most OPC Servers for Modbus support ASCII as well as RTU communications.. What are extended register addresses? Since the range of the analog output holding registers is 40001 to 49999, it implies that there cannot be more than 9999 registers. Although this is usually enough for most applications, there are cases where more registers would be beneficial. Registers 40001 to 49999 correspond to data addresses 0000 to 270E. If we utilize the remaining data addresses 270F to FFFF, over six times as many registers can be available, 65536 in total. This would correspond to register numbers from 40001 to 105536. Many modbus software drivers (for Client PCs) were written with the 40001 to 49999 limits and cannot access extended registers in server devices. And many server devices do not support maps using the extended registers. But on the other hand, some server devices do support these registers and some Client software can access it, especially if custom software is written. How does 2-byte server addressing work? Since a single byte is normally used to define the server address and each server on a network requires a unique address, the number of server on a network is limited to 256. The limit defined in the modbus specification is even lower at 247. To get beyond this limit, a modification can be made to the protocol to use two bytes for the address. The client and the servers would all be required to support this modification. Two byte addressing extends the limit on the number of servers in a network to 65535. By default, the Simply Modbus software uses 1 byte addressing. When an address greater than 255 is entered, the software automatically switches to 2 byte addressing and stays in this mode for all addresses until the 2 byte addressing is manually turned off. How can you send events and historical data? Enron Modbus includes commands for moving events and historical data.. What is Enron Modbus? Enron Modbus is a modification to the standard Modicon modbus communication protocol developed by Enron Corporation. See Enron Modbus for details.

Question 4

Video: Replacing the Battery in a Smart-UPS

Accepted Answer

Issue: Smart-UPS requires battery replacement. Product line: Smart-UPS Environment: All models, all serial numbers. Cause: Smart-UPS batteries require replacement every 3-5 years. This document will assist you in replacing the battery. Resolution: Click Here to search by part number for the exact Smart-UPS unit you are using.On the product page of each Smart-UPS unit you will find a link to the user's manual on the "Documentation" tab. The manual for each unit will explain the battery replacement procedure.If your UPS is not listed your UPS may not have user replaceable batteries. Please contact our Customer Solutions Team for more information: https://www.se.com/ww/en/work/help/ Please refer to your users manual for the procedure for your specific model.

Question 5

How do I upgrade the firmware on an APC Network Management Card (NMC) or NMC embedded device?

Accepted Answer

Issue You wish to upgrade your Network Management Card's (NMC) firmware or have been instructed to.You have a device such as a Smart-UPS, Smart-UPS Ultra, Easy UPS On-Line, Easy UPS 3-Phase, Rack PDU, AV unit, or environmental monitoring unit with an embedded NMC that you wish to upgrade.You had a problem with a previous upgrade attempt and need the instructions in order to correct it.Your device came pre-loaded with the wrong application and you need to load the correct application. Product Line Network Management Card 2 - AP9630, AP9631, AP9635Network Management Card 3 - AP9640, AP9641, AP9643Network Management Card 3 for Easy UPS – AP9544, AP9547Network Management Card 4 – AP9644 Environment All serial numbersAll firmware versions (unless otherwise noted) CauseUsers may wish to upgrade their firmware to take advantage of enhancements, bug fixes, or new features. Also, sometimes a firmware upgrade can be interrupted or unsuccessful and these instructions can be followed to remedy the problem.Typically, these upgrades do not require the device the Network Management Card is installed in to be powered down or cause unnecessary downtime.Lastly, downgrades are not typically recommended but the manual methods can also be used to do those in certain circumstances.NOTE: To upgrade to firmware version 3.0 and higher for NMC3 for Smart-UPS, Easy UPS On-Line, and rPDU, the only supported method is the Secure NMC System (SNS) Tool, which requires a subscription to access the firmware. For more information, see www.se.com/secure-nmcResolutionFind Correct FirmwareWhen upgrading the firmware on your Network Management Card (NMC), you will need to determine which files pertain to your application. Begin by determining what model of NMC you have. AP9630, AP9631, AP9635 - Network Management Card 2AP9641, AP9641, AP9643 - Network Management Card 3AP9544, AP9547 - Network Management Card 3 for Easy UPS The application firmware required depends on what product your NMC is installed in. Some examples include: For NMC2 devices: SUMX for Smart-UPS 1-PhaseSY for Symmetra 1-Phase UPSSY3P for Symmetra 3-Phase UPS For NMC3 devices: SU for Smart-UPS 1-PhaseSY for Symmetra 1-Phase UPSSUCAN for Smart-UPS UltraRPDU2G for rPDU (Rack Power Distribution Unit)SY3P for Symmetra 3-Phase UPS For Easy UPS NMC devices: EU1P for Easy UPS 1-PhaseEU3P for Easy UPS 3-Phase NOTE: These instructions can also be used in devices that have embedded (mini) versions of the above Network Management Cards.NOTE: If you are interested in upgrading multiple devices at a time, refer to knowledge base FA156117 NOTE: If you have an AP9635 installed in a Symmetra PX 250/500, you have a Network Management Card 2 but MUST contact APC Technical Support in order to obtain the correct firmware and special instructions.Download Firmware Navigate to www.apc.com/secure-nmc and click the Software and Firmware tab.Find and download the latest firmware file for your NMC. NOTE: To upgrade to firmware version 3.0.0 and higher for NMC3 for Smart-UPS, Easy UPS On-Line, and rPDU, the only supported method is the Secure NMC System (SNS) Tool, which requires a subscription to access the firmware.Alternatively, visit https://www.apc.com/us/en/download/software-firmware/ and enter your NMC part number (e.g. AP9641), click the Firmware category, and download the latest firmware file. NOTE: Firmware updates of NMC3 or NMC4 for 3-Phase UPS and PDU can only be done by Schneider Electric qualified services representatives. Please contact your local Schneider Electric Service Representative or Schneider Electric Certified Service Partner for details. Update FirmwareThere are different ways that you can upload the firmware for each device. Please choose a method that works best for you. NOTE: For users upgrading (or downgrading) their Network Management Card 2 device from v5.X.X to v6.X.X, please review Knowledge Base article FA167693 to understand several important considerations prior to beginning any of these steps. Secure NMC System (SNS) Tool - Network Management Card 3 (for firmware versions 3.0 and higher)Universal Serial Bus (USB) 1.1 - Network Management Card 2 and 3 devices with a USB port (AP9631, AP9635, AP9641, AP9643 and RPDU devices (RPDU2G) and Smart-UPS Ultra devices with embedded NMC3 – for firmware versions 2.5 and lower)Firmware Upgrade/Update Utility - Network Management Card 2 and 3 (for NMC3 firmware versions 2.5 and lower)XMODEM - Network Management Card 2 and 3 (for NMC3 firmware versions 2.5 and lower)Manual (FTP prompt) - Network Management Card 2 and 3 (for NMC3 firmware versions 2.5 and lower)Manual - Secure CoPy (SCP) - Network Management Card 2 and 3 (for NMC3 firmware versions 2.5 and lower) Secure NMC System (SNS) Tool - Network Management Card 3 (firmware versions 3.0 and higher) Download the Secure NMC System (SNS) Tool from the APC/Schneider Electric website. As of SNS Tool v4.0, all units can be upgraded using the same program, excluding PDU's in an NPS setup. Part # (SKU) Secure NMC System (SNS) Tool SFNMC3FMTSU Secure NMC System Tool for Smart-UPS SFNMC3SUCAN Secure NMC System Tool for Smart-UPS Ultra SFNMC3RPDU Secure NMC System Tool for PDU SFNMC3FMTEU1PSecure NMC System Tool for Easy UPS On-Line NOTE: There are different versions of the SNS Tool depending on the application you are running on your NMC3. To access the firmware in the SNS Tool, you need a valid Secure NMC subscription. See www.apc.com/secure-nmc for more information. Double-click the self-extracting ZIP file. Add devices to the SNS Tool: To add one at a time: Click Add Devices and enter: the NMC’s IP address/FQDN/hostname the protocol and port to transfer the firmware file. SCP is recommended as it’s more secure than FTP. Note: The selected protocol must also be enabled on the NMC3. the user name and password To add more than one at a time: Open the devices.csv file in the downloaded SNS Tool directory and add the device details. Note: Lines that start with a semi-colon ; will not be processed. Save and close the devices.csv file. In the SNS Tool, click Add Devices. Click Import Device File – this button only appears if data is detected in the devices.csv file. Click Query Devices. Click Query Devices. Click Add Devices. Activate licenses for selected NMCs: Click on NMCs in the Device List and click License Devices. If you have more than 1 NMC in the Device List, use Ctrl+click to multi-select. Enter the Activation ID from the purchased Secure NMC System subscription and click Confirm & Activate. (If you have the SNS Tool installed on another PC and want to check if any of the NMCs are already licensed, you can click Sync License(s) to do so). Update firmware for selected NMCs: Click on NMCs in the Device List and click Update Firmware. If you click Update Firmware without selecting any NMCs from the Device List, the Firmware Management Tool will automatically select all of the NMCs that are eligible to update (Device Status = Ready for update). Universal Serial Bus (USB) 1.1 – Network Management Card 2* devices with USBNOTE: *If you have an AP9635 installed in a Symmetra PX 250/500, you have a Network Management Card 2 but MUST contact APC Technical Support in order to obtain the correct firmware and special instructions, PRIOR to following the steps below. Failure to do so may result in unexpected operation of your AP9635 Network Management Card 2. NOTE: Some USB flash drives are not compatible with the NMC2 devices. Secondly, the flash drive’s file system must be FAT, FAT16, or FAT32. (NTFS will not work).1. Obtain the latest firmware files from apc.com and extract them to a folder. Please note, USB may not allow for a firmware downgrade. You must use a manual method to accomplish a downgrade.2. Create a folder on your USB flash drive called apcfirm .3. From the latest firmware files that you downloaded, add to the apcfirm folder the binary files for the firmware modules that you would like to upgrade. Some examples of the binary files for the three firmware modules follow: Firmware ModuleBinary File APC Boot Monitor apc_hw05_bootmon_109.bin APC Operating System (AOS) apc_hw05_aos_712.bin Application Module apc_hw05_sumx_712.bin Language Pack* sumx_712_frFrdeDeruRuitItesEs.lpk *Optional language pack upgrades/changes are supported via USB if the device you’re upgrading already has BootMonitor v1.0.8 or higher (BootMonitor performs the upgrading function). NOTE: Not all NMC2 applications support language packs. 4. Use a text editor such as Microsoft Notepad to create a file called upload.rcf. NOTE: (Ensure that file extensions are visible so that your file does not get named upload.rcf.txt. In Windows, this option can be edited in Folder Options->View->Hide extensions for known file types within Control Panel. Make sure that option is unselected.) Add to the file a line for each firmware module that you want to upgrade as shown below (replace “xx” with the version of firmware you will be upgrading to): BM=apc_hw05_bootmon_xx.binAOS=apc_hw05_aos_xx.binAPP=apc_hw05_sumx_xx.binLANG=sumx_xx_frFrdeDeruRuitItesEs.lpk 5. Add the upload.rcf file to the apcfirm folder on the flash drive.6. Insert the flash drive into the USB port on the NMC2.7. Press and release the pinhole Reset button on the NMC2 for the USB upgrade process to begin. (This will only reboot the management interface of the NMC2 and not reboot your device/load.) The NMC2 status LED, located on the RJ-45 Ethernet jack, will begin to blink amber during this procedure and rotate through a few color flashing patterns while transferring the different files. NOTE: If you have an AP9631 or AP9635 removable NMC2 UPS SmartSlot card, you can also remove and re-insert the card into the UPS SmartSlot, effectively rebooting the NMC2 and beginning the USB upgrade process this way.8. Wait for 2-5 minutes for the upgrade to complete. Remove the flash drive from the USB port and check your firmware version. On a Rack PDU specifically, the LCD display will show the firmware version for three seconds and then will resume normal operation, at which time you can also remove the flash drive.Universal Serial Bus (USB) 1.1 – Network Management Card 3 devices with USB (firmware versions 2.5.0 and lower)This feature is available in bootloader version v1.3.3.1 and higher. Before starting the transfer, make sure the USB drive is formatted in FAT, FAT16 or FAT32. Download the firmware upgrade file.Create a folder named apcfirm on the USB flash drive.Place the .nmc3 file in the apcfirm directory.Use a text editor to create a file named nmc3.rcf. (The file extension must be .rcf, not .txt for example.)In nmc3.rcf, add a line for the firmware package to be upgraded. For example, to upgrade Smart-UPS application version v1.5.0.6, type: NMC3=apc_hw21_su_2-5-0-6.nmc3Place nmc3.rcf in the apcfirm folder on the flash drive.Insert the flash drive into a USB port on your NMCReboot the NMC and wait for the card to reboot fully. Firmware Upgrade/Update Utility – Network Management Card 2 and 3* (NMC3 firmware versions 2.5.0 and lower)If you have a Windows computer, you can use the Firmware Upgrade Utility (NMC2)/Firmware Update Utility (NMC3) to upgrade the firmware.If you have any other type of computer, then you will need to manually upload each firmware file to the Network Management Card. Go to the XMODEM or Manual sections below for additional instructions.NOTE: For any firmware downgrades, which are not typically recommended, you will need to choose a new method. The Wizard will block any downgrades. Unfortunately, loading applications for different devices may also have encounter this block if AOS versions are not the same.NOTE: *If you have an AP9635 installed in a Symmetra PX 250/500, you have a Network Management Card 2 but MUST contact APC Technical Support in order to obtain the correct firmware and special instructions, PRIOR to following the steps below. Failure to do so may result in unexpected operation of your AP9635 Network Management Card 2. Click on the firmware executable once the download is complete. The executable will proceed to unzip firmware files and extract them. You can specify the location where you want the firmware to download to.Once the firmware has been saved, the executable will prompt you for the IP address of the Network Management Card that you want to upgrade.Once you enter the IP address, click enter.You will be prompted for a username and password. This must be the Super User Account or an Administrator account. By default, the Super User username and password is apc. Press enter.If using the NMC2 Firmware Upgrade Utility, seen below, you will be prompted to enter the IP address and username and password. You can enter those and press Upgrade Now. If using the NMC3 Firmware Update Utility, seen below, you will be prompted to enter the IP address and username and password. You can enter those and press Start Update. The firmware executable will then begin the upgrade process. This process may take as long as 5-7 minutes to finish. Once finished, close the executable.Verify that the firmware upgrade was successful. Log into the Web UI and navigate to About -> Network. The updated firmware should be listed on this page. Alternatively, verify via Telnet, SSH, or local console connection on the main page after log in. XMODEM – Network Management Card 2 and 3 (for NMC3 firmware versions 2.5 or lower) Network Management Card 2 (AP9630, AP9631, AP9635)*NOTE: If you have an AP9635 installed in a Symmetra PX 250/500, you have a Network Management Card 2 but MUST contact APC Technical Support in order to obtain the correct firmware and special instructions, PRIOR to following the steps below. Failure to do so may result in unexpected operation of your AP9635 Network Management Card 2.NOTE: If you wish to downgrade from v6.X.X to v5.1.X firmware on NMC2, please make sure you review Knowledge Base Article FA167693 prior.1. Select a serial port at the local computer and disable any service that uses the port.2. Connect the provided serial configuration cable (APC part number 940-0299) to the selected 2.5mm Tip-Ring-Sleeve Console port on the Management Card itself. 3. Run a terminal program such as HyperTerminal, and configure the selected port for 57600 bps, 8 data bits, no parity, 1 stop bit, and no flow control. NOTE: certain terminal emulation programs, such as PuTTy, do not support the XMODEM protocol.4. Press the Reset button on the Management Card or reseat the Network Management Card in the SmartSlot, then immediately start pressing the key repeatedly until the Boot Monitor prompt displays: BM> . Also, once you have entered Boot Monitor mode correctly, the Network Management Card's status LED will flicker amber in color. (BootMonitor mode is required on NMC2 for an XMODEM upgrade in any situation.)5. Type XMODEM, then press ENTER. You will begin to see CCCCC scroll across the screen to indicate the Network Management Card is ready to receive a file.6. From the terminal program’s menu, select XMODEM, then select the binary bootmonitor firmware file to transfer using XMODEM. After the XMODEM transfer is complete, the Boot Monitor prompt returns.NOTE: If the boot monitor module must be updated, a boot monitor module is included in the firmware release. Otherwise, the boot monitor module that is installed on the card is compatible with the firmware update. If there is no included bootmonitor file, upgrade the AOS binary first.7. To install the application module, repeat step 5 and step 6. In step 6, use the application module file name.8. Type reset or press the Reset button to restart the Management Card.If the Management Card is installed in an Expansion Chassis or Triple Expansion Chassis, connect the provided configuration cable (APC part number 940-0299) to the serial port at the Management Card, or connect an RS-232 configuration cable (APC part number 940-0024) to the DB-9 serial port at the expansion chassis.If you connect an RS-232 configuration cable (APC part number 940-0024) to the DB-9 serial port of the expansion chassis, select 115200 bps.Network Management Card 3 (AP9640, AP9641, AP9643)1. Select a serial port at the local computer and disable any service that uses the port.2. To connect to a NMC3, use the provided micro-USB cable (APC part number 960-0603).3. Run a terminal program such as HyperTerminal, and configure the selected port for 57600 bps, 8 data bits, no parity, 1 stop bit, and no flow control. NOTE: Certain terminal emulation programs, such as PuTTy, do not support the XMODEM protocol.4. Press the Reset button on the Management Card or reseat the Network Management Card in the SmartSlot, then immediately start pressing the key repeatedly until the Boot Monitor prompt displays: BM>. Once you have entered Boot Monitor mode correctly, the Network Management Card 3's status LED will be solid orange in color. (Boot Monitor mode is required on NMC3 for an XMODEM upgrade in any situation.)5. Type XMODEM, then press ENTER. You will begin to see CCCCC scroll across the screen to indicate the Network Management Card is ready to receive a file.6. From the terminal program’s menu, select XMODEM and select the .nmc3 file to transfer. After the XMODEM transfer is complete, the Boot Monitor prompt returns.7. Type reset or press the Reset button to restart the Management Card.If the Management Card is installed in an Expansion Chassis or Triple Expansion Chassis, connect the provided configuration cable (APC part number 940-0299) to the serial port at the Management Card, or connect an RS-232 configuration cable (APC part number 940-0024) to the DB-9 serial port at the expansion chassis. If you connect an RS-232 configuration cable (APC part number 940-0024) to the DB-9 serial port of the expansion chassis, select 115200 bps. Manual (via FTP) - Network Management Card 2 and 3* (NMC3 firmware versions 2.5.0 and lower)Network Management Card 2NOTE: If you have an AP9635 installed in a Symmetra PX 250/500, you have a Network Management Card 2 but MUST contact APC Technical Support in order to obtain the correct firmware and special instructions, PRIOR to following the steps below. Failure to do so may result in unexpected operation of your AP9635 Network Management Card 2.1. To perform a firmware flash with this method the Management Card must have been previously configured with a System IP, Subnet Mask, and Default Gateway and attached to the network. In addition, FTP Server must be enabled.2. Open an MS-DOS command prompt window on a PC which is connected to the network. Change to the directory which contains the firmware upgrade files. Some example commands which need to be entered are shown in bold in order to change directories. Please note, this is just an example. You may need to enter a full path to a directory which requires different syntax.C:\> cd apcC:\apc> 3. Open an FTP client session.C:\apc> ftp 192.168.1.100 (192.168.1.100 being the IP address of the web card) 4. Log in. This must be the Super User Account or an Administrator account. By default, the Super User username and password is apc. Press enter.Typically, the password will appear on the screen as *** or not at all as you type. Connected to 192.168.1.100220- APC FTP server ready.User (192.168.1.100 :(none)): apc331 User name okay, need password.Password: apc230 User logged in, proceed.ftp> 5. Upgrade the bootmonitor file first. If the boot monitor module must be updated, a boot monitor module is included in the firmware release. Otherwise, the bootmonitor module that is installed on the card is compatible with the firmware update and can be skipped. If there is no included bootmonitor file, or you are using NMC1, upgrade the AOS first. The AOS module is the file with the AOS prefix. ftp> bin (specifies binary transfer mode which is required)200 Command okay.ftp> hash (optional - enables hash mark printing as a way of monitoring file transfer progress)ftp> put aosxx.bin (xx being the version number downloaded) Tip: With Windows Command Prompt in most OS versions, besides Vista, command prompt, you can drag and drop the file onto the command prompt window which will paste the full file path automatically here for you.200 Command okay.150 Opening data connection for aos301.bin###############################################################250 Requested file action okay, completed. Management Card Rebooting....327680 bytes sent in 5.99 seconds (54.70 Kbytes/sec)ftp> 6. Close the FTP client session to allow the card to continue rebooting as your FTP session will be disconnected and need to be re-opened for any further transfers. ftp>byeC:\apc> 7. Wait about 20 - 30 seconds.8. Repeat Steps 3 - 8 again for the application module (sumx for Smart UPS/Matrix, sy for Symmetra, etc). In Step 6, substitute the sumx module file name, in place of the AOS module file name. Or the sy prefix for the Symmetra. NOTE: To upgrade multiple Management Cards using an FTP client or using SCP, write a script which automatically performs the procedure.NOTE: If using MacOSX, the full filepath of the destination folder will need to be included in the "put" command. An example command would read:ftp> put /Users/Admin/Downloads/aosxx.bin /aosxx.binNetwork Management Card 31. To perform a firmware flash with this method the Management Card must have been previously configured with a System IP, Subnet Mask, and Default Gateway and attached to the network. In addition, FTP Server must be enabled.2. Open an MS-DOS command prompt window on a PC which is connected to the network. Change to the directory which contains the firmware upgrade files. Some example commands which need to be entered are shown in bold in order to change directories. Please note, this is just an example. You may need to enter a full path to a directory which requires different syntax.C:\> cd apcC:\apc>3. Open an FTP client session.C:\apc> ftp 192.168.1.100 (192.168.1.100 being the IP address of the web card) 4. Log in as Administrator (apc is the default user name and password). 5. Upgrade the firmware:ftp> bin (specifies binary transfer mode which is required)ftp> hash (optional - enables hash mark printing as a way of monitoring file transfer progress)ftp> put apc_hw21_SU_xx.nmc3 (xx being the version number downloaded)6. When FTP confirms the transfer, type quit to close the session. 7. Wait about 20 - 30 seconds. NOTE: To upgrade multiple Management Cards using an FTP client or using SCP, write a script which automatically performs the procedure.Manual (via Secure CoPy) - Network Management Card 2 and 3* (NMC3 firmware versions 2.5.0 and lower)Network Management Card 2NOTE: If you have an AP9635 installed in a Symmetra PX 250/500, you have a Network Management Card 2 but MUST contact APC Technical Support in order to obtain the correct firmware and special instructions, PRIOR to following the steps below. Failure to do so may result in unexpected operation of your AP9635 Network Management Card 2.NOTE: If you wish to downgrade from v6.X.X to v5.1.X firmware on NMC2, please make sure you review Knowledge Base Article FA167693 prior.1. Identify and locate the firmware modules described in the preceding instructions for FTP.2. Use an SCP command line to transfer the AOS firmware module to the Management Card. The following example uses xx to represent the version number of the AOS module: scp apc_hw05_aos_xx.bin apc@158.205.6.185:apc_hw05_aos_xx.bin 3. Use a similar SCP command line, with the name of the application module, to transfer the application firmware module to the Management Card. NOTE: To upgrade multiple Management Cards using an FTP client or using SCP, write a script which automatically performs the procedure. Alternatively, you can use APC's INI utility which is downloadable and explained in Knowledge Base Article FA156117.NOTE: Never remove a Management Card before it completes the reboot cycle. Doing so will damage the Management Card. The reboot cycle is complete when the status LED turns off and after 20 seconds turns solid green or slowly flashing Network Management Card 3Use an SCP command line to transfer the .nmc3 file to the Management Card. The following example uses xx to represent the version number of the application module: scp apc_hw21_SU_xx.nmc3 apc@158.205.6.185:apc_hw21_SU_xx.nmc3 NOTE: To upgrade multiple Management Cards using an FTP client or using SCP, write a script which automatically performs the procedure. Alternatively, you can use APC's INI utility which is downloadable and explained in Knowledge Base article FA156117.NOTE: Never remove a Management Card before it completes the reboot cycle. Doing so will damage the Management Card. The reboot cycle is complete when the status LED turns off and after 20 seconds turns solid green or slowly flashing amber.

Question 6

METSEEMD461R Modbus Registers

Accepted Answer

Issue I cannot find the Data Sheets, Installation Guide, User Manual, and Modbus Register List for the METSEEMD461R Dual Connect Meter Product Line Rayleigh METSEEMD461R Environment Low Voltage Current Transformers Resolution Please find the attached Data Sheets, Installation Guide, User Manual, and Modbus Register List for the METSEEMD461R Dual Connect Meter

Question 7

Do we have a document for Clipsal Iconic cut-out template?

Accepted Answer

Yes, see the attached file. 1 to 4 gang switch plate cut-out template 5 and 6 gang switch cut-out templates Architrave switch cut-out temple Socket cut-out template 4 gang socket cut-out template

Question 8

What does B,C,D curve mean for Acti 9 MCB?

Accepted Answer

B Curve means the MCB trips between 3-5 times full load current. It is mainly used in residential applications where loads are resistive e.g. lighting fixtures, domestic appliances with low surge Levels.C Curve means the MCB trips between 5-10 times full load current. It is used in commercial/industrial applications where there is greater chances of higher short circuit currents e.g. mainly inductive loads , fluorescent lighting.D Curve means the MCB trips between 10-14 times full load current. It is used where inrush currents can be very high e.g. motors, X-ray machines.Here is the curves diagram:

Question 9

What does the term "NEMA Type 1A" refer to?

Accepted Answer

NEMA Standards Publication 250-1997, "Enclosures for Electrical Equipment (1000 Volts Maximum)" no longer lists this enclosure type. This enclosure type is commonly accepted to be referring to a NEMA 1 enclosure with a gasketed cover.

Question 10

What is difference between BL and BD coils?

Accepted Answer

The difference between BL and BD Coils is a BL coil has a lower power consumption which is good for a contactor ONLY (no auxiliaries attached). Wherefore a BD coil has a normal power consumption but has the capability to use auxiliaries.

Question 11

How do I access the Tools Page in eDLT

Accepted Answer

Press and hold down the bottom left button, whilst continuing to hold then double press the top right button.Please note that access to the Tools Page can be disabled using C-Bus Toolkit software.

Question 12

Why choose Type B RCD for 3 Phase Variable Speed Drives?

Accepted Answer

For the 3 Phase Variable Speed Drives, the RCD type B or type B-Si is particularly suitable.It protects against fault currents with DC offset, which is true for three-phase power converters. In addition, it has enhanced immunity against nuisance tripping caused by: EMC common mode filters connected upstream VSD.Type B has a tripping delay allowing the inrush current to flow on power up.The permanent switching leakage currents existing in power converters (ex: 25kHz).Type B includes a "low pass" filter to ensure a trigger threshold that increases with frequency while complying with the personal protection curve (fibrillation). Please note: if the required sensitivity is 300mA, Selective type RCD should be proposed ensuring a non-triggering time of 50ms. More information can be found on the Earth Fault Protection guide: https://download.schneider-electric.com/files?p_enDocType=Catalog&p_File_Name=CA908066E+%28web%29.pdf&p_Doc_Ref=CA908066EWith regards to installation of these RCDs, they are mounted upstream of the Variable Speed Drives.See below example Schneider Electric offers Acti9 iID range of 4 Pole RCDs type B available in 30 mA sensitivity and type B-Si available in 30 and 300 mA sensitivity (Selective type is available) Click this link below to view the complete range of Acti9 iID RCDs available in Australia: https://www.se.com/ww/en/product-country-selector/?pageType=product-range&sourceId=7559&N=781354987+3098582207+2355967283+39384534

Question 13

How can I cable to the PNP and NPN type outputs for sensors / detectors, using the wiring diagram?

Accepted Answer

PNP and NPN type outputs are available as 3-wire sensors with a DC voltage power supply (the voltage limits are dependent on the specific sensor): PNP type: switching on the positive voltage load NPN type: switching on the negative voltage load These outputs are typical of photoelectric detectors, inductive proximity and other types of sensors.For a detailed explanation of PNP vs NPN, see the following FAQ: FA142566 PNP output The load (relay coil, contactor relay input, PLC input) must be connected between the "-" negative terminal and the midpoint. The corresponding PLC input is Sink. NPN output The load must be connected between the "+" positive terminal and the midpoint. The corresponding PLC input is Source. Some sensors have two PNP and NPN outputs (4-wire sensors) which are wired according to the diagram below.Note that we no longer sell sensors. Telemecanique Sensors, who were previously part of the Schneider Electric brand, were sold in 2023. You can go to their website - www.telemecaniquesensors.com - for more information, including contact details.

Question 14

What is the selection criterion of Circuit Breakers for the Capacitor bank application.

Accepted Answer

The selection should be done after derating the Circuit Breaker taking into consideration voltage variation and capacitors tolerances that could increase nominal current up to 1.5In. The Derating factor of 1.5In Where In = Q/ ( Square root of 3 ) Un Q = Capacitor Power Un = Nominal Voltage Choose the Micrologic with delay time selection, so that the Circuit Breaker does not trip due to initial high inrush current. Also to be taken into account are the parameters like supply frequency, operating voltage & harmonics level of the power system for such application. Refer the attached sheet for further details for selection of Circuit Breaker for Capacitor duty application. Note: Use the phase barrier between the phases in Circuit Breaker to prevent flashover due to heavy inrush current.

Question 15

What are the effects of dV/dt on a Motor when using a VSD?

Accepted Answer

As there is an impedance mismatch at the termination of the motor cable to the motor, there will be a reflected wave which travels back along the motor cable causingovervoltage’s. Overvoltage’s on the motor terminals can cause both partial and corona discharge which eventually wears down the winding insulation to failure. Corona discharge occurs when the overvoltage is large enough to cause electrons to flow from one winding to another whilst ionising the air between the conductors. They cause damage to the internal and external insulating material respectively. As the motor cable length increases the peak voltage increases. This can increase to a value of 2 to 2.5 times the DC bus voltage. Schneider Electric Offer Sinus filters or dv/dt filters to reduce the overvoltage across windings and high frequency currents in differential mode. Check out our current ATV600 or ATV900 catalogue for more information on output filters to help you with overvoltage mitigation.

Question 16

What is DPF ?

Accepted Answer

Displacement Power FactorDisplacement Power Factor is caused by a reactive component in the load.
