Discover EcoStruxure I/O Smart Link

Benefits of EcoStruxure I/O Smart Link

Simple

Offers simple wiring to devices using prefabricated cables to avoid miscabling and optimise installation.
Sustainable

Provides compliance with the latest regulations, transparency on environmental impacts, as well as circular and low-CO2 products.
Efficient

Enables performance notifications to help ensure power availability for business continuity and reduce energy consumption.

Features of EcoStruxure I/O Smart Link

Modularity

The modular interface allows operators to remotely measure, monitor, and control the essential functions of one or more devices, such as Acti9 circuit breakers, contractors, and pulse metres.

Connectivity

Simple, rapid installation with a ready-to-connect communication module that uses the most universal and open communication protocol of Modbus (SCADA serial master), and all-in-one cable pluggable connections. Eleven IEC 61131-2 complaint digital input/output channels and the option to establish an ethernet connection with EcoStruxure Panel Server.

Easy modifications

Maintenance is efficient and flexible thanks to clear and reliable control wiring. Availability of adaptation to building usage upgrades and optional specification changes before commissioning.

Wide data scope

Comprehensive data collection allows for monitoring of a full scope of available information, including:

open status, tripped status, number of openings, and number of trippings in protection devices
open/close status, number of switchings, load running hours in control devices
number of pulses, consumed energy, flow/power indication in metering devices

Native integrations

Built-in integration with our EcoStruxure solutions

Safety

Meets the latest compliance protocols for control and metering connections

Applications

EcoStruxure I/O Smart Link can be connected to the EcoStruxure Panel Server, Building Management System, or any other building management application for remote management of I/O assets. EcoStruxure I/O Smart Link enables:

Seamless measurement and monitoring of the loads

Support control operations of the loads

Energy metering of the low-cost pulse metres

Easy maintenance, thanks to providing operational counters and other counters for each load

Trending of energy consumption of the Pulse Metres can be achieved using EcoStruxure Panel Server or advisors
EcoStruxure I/O Smart Link can be connected to EcoStruxure Panel Server, SCADA, or remotely manage the I/O assets connected to industrial applications. EcoStruxure I/O Smart Link enables:

Remote measurement and monitoring of the load status

Remote control operations of the loads

Energy metering of the pulse metres

Preventive maintenance, thanks to providing operational counters and other counters for each load
