Upgrading from the PDL range to the ATV range couldn’t be simpler. We have two comprehensive migration guides (bottom of this page) to help you plan and compare the products as well as Applications, Technical and Engineered Services & Support for help and advice.
Click on the table to find the preferred ATV upgrade. You now have a choice between drives for Variable Torque (VT) applications, such as pumps fans etc or Constant Torque (CT) general machinery applications. Both drives are available in IP20 and IP54 with common features and accessories. If you can’t find what you’re looking for or need further help, please contact us.
|
Single Phase Input Variable Speed Drives |
||
| PDL Reference |
Pump/ Fan (VT) |
General (CT) |
| Xtravert (X302 to X309) | ||
| Mini Microdrive
MKII Microdrive Picodrive |
||
|
Three Phase Input Variable Speed Drives |
||
|
PDL Reference |
Pump/ Fan (VT) |
Machinery (CT) |
| Xtravert (X702 to X716) | ATV61 | ATV71 |
|
Microdrive Elite (ME-2.5 to ME-46)
|
||
|
Older PDL Three Phase Input Models |
||
|
PDL Reference |
Pump/ Fan (VT) |
Machinery (CT) |
|
Microdrive 3 (UD3-2.5 to UD3-70)
|
||
|
Microflo 3 (MF3-2.5 to MF3-70)
|
N/A |
|
|
Microvector 3 (MV3-2.5 to MV3-70)
|
N/A |
|
|
Application Notes and Migration Guides |
|
|
Xtravert to ATV71 |
Elite to ATV71 |
|
|
|
