Discover VigiPacT

Vigipact relays detect insulation faults by continuously monitoring earth leakage current. Then they offer 2 options : • Protection: when leakage current reaches the set threshold, they trip the circuit-breaker upstream, by activating its shunt trip auxiliary. • Monitoring and alarming, by LED, bar graph, or digital touchscreen on front, and by a dry contact output. Multi-line versions are capable of monitoring up to 12 lines with one device, connected to 12 current sensors.

Benefits of VigiPacT

Reliable protection

• Self-monitoring - every internal failure is notified. • Access to settings is locked while other buttons remain at your disposal. • ComPacT circuit-breakers – complete switch off within 40 ms after the set time delay. • Overvoltage withstands category IV for A type – category III for B type.
Minimised downtime

• Trip time delays enable the selectivity between earth-fault protections. • No trip under leakage currents below 80% of the set threshold (vs standards tolerance down to 50%). • No trip under transient leakage currents, caused for instance by capacitor charging, or by motor or transformer switching.
Optimised continuity

• Sensitivity to harmonics adapted to hazardous leakage intensity at every frequency. • True RMS earth-leakage current monitoring • Inverse-time tripping curve. • Test without trip available.
Sustainable and certified

• ISO 14001-certified manufacturing sites. • Green Premium labelled. • All parts marked for sorting and recycling purposes. • Designed using EIME software (Environmental Information and Management Explorer). • RoHS and REACh compliant.

Get to know features

Sensitivities and time delays

• A type relays fixed or adjustable from 30mA to 30A. • B type relays adjustable from 30mA to 3A. • Trip time delay ranges from 0 to 4,5 seconds - fixed or adjustable.

For most demanding locations

• Suitable for networks with operating voltage up to 1000 V and frequencies up to 400 Hz. • Monitor lines of capacity up to 3200 A (and switch them off when combined with ComPacT circuit-breaker). • Suitable for main switchboards in the most demanding environments (overvoltage withstand category IV and category III for B-type).

Certified and compliant worldwide

• IEC 60 755 and IEC 60947-2 appendix M (certificates by Kema laboratories available). • UL 1053 listed, CSA C22.2 N° 144 for North-America. • CCC for China.

See the applications for A-type VigiPact relays

Up to 1000 V and 400 Hz

Electrical networks with voltage above 500 V (up to 1000 V) and frequency higher than 60 Hz (up to 400 Hz)
Up to 3200 A

Distribution lines with capacity 630 A and above (up to 3200 A)
Switchboard upgrades

Adding earth-leakage protection to switchboards already operating.
Up to 200 kA

Compatible with prospective short-circuit currents up to 200 kA.

Check the applications for B-type VigiPact relays

Three-phase drives and rectifiers

Embedded in : lifts, cranes, HVAC, high-power speed drives, UPS, etc.
Electric vehicle DC boosts

Single-phase DC boost power supply in some electric vehicle chargers.
Single phase drives

Loads including single-phase speed drives: washing machines, air-conditioning units, heat pumps, food processors, etc.
Harmonic filters

Power supply network equipped with harmonic filters.
