Issue:
Door for Bus plug port

Product Line:
Busway

Environment:
I-Line and I-Line 2

Cause:
Replacement Parts

Resolution:

The door cannot be purchased separately. The customer will have to purchase the entire Plug-In Base Assembly, which will come with a new hinged door. The P/N for the Plug-In Base Assembly is 45204-728-50.  Colors of the base and door are subject to change...ie. some bases are red , some grey; some doors are black , some grey .      If the (2) attachment screws for the original plug-in base assembly cannot be reused, order qty (2) screws, P/N 21594-18200, to affix the new plug-in base assembly to the busway housing.

Released for: Schneider Electric USA
