Issue:
Repair parts list for HU361RB, series F1
Product Line:
Safety Switches
Resolution:
The repair parts for the HU361RB, series F1(F01) are as follows. No other parts are available.
Line/Load Base Assembly -4056642650 (1 required; arc suppressor assembly not included)
Arc Suppressor Assembly - 4056669451 (1 required)
Lug Assembly - 4025101652 (per lug)
Switch Mechanism - 4056610750
Handle Assembly - 4056684150K
Handle Gasket - 4056603101
Lockplate - 4056637601
Repair parts list for HU361RB, series F1
Product Line:
Safety Switches
Resolution:
The repair parts for the HU361RB, series F1(F01) are as follows. No other parts are available.
Line/Load Base Assembly -4056642650 (1 required; arc suppressor assembly not included)
Arc Suppressor Assembly - 4056669451 (1 required)
Lug Assembly - 4025101652 (per lug)
Switch Mechanism - 4056610750
Handle Assembly - 4056684150K
Handle Gasket - 4056603101
Lockplate - 4056637601
Released for: Schneider Electric USA
