Discover Acti9 iID

Benefits of Acti9 iID

Modularity & adaptability

• Ratings from 16 to 100A• Tripping sensitivity from 10mA to 500mA• Tripping time either ‘Instantaneous’ or ‘Selective’• A wide range of protection classes to cover all earth leakage waveforms and electromagnetic and environmental conditions• Wide range of electrical auxiliaries and accessories
Ease of operation

Monitoring and control Acti9 iID RCCB thanks to a wide range of indicating and actuating auxiliaries to:• Quickly identify the source of the earth leakage fault thanks to VisiTrip mechanical flag on product front face• Carry out downstream maintenance safely with guaranteed contact opening thanks to VisiSafe green strip on the iID toggle• Easily remove Acti9 iID RCCB from DIN rail with comb busbar in place thanks its top and bottom locking clips
Enhanced safety and continuity of service

• Its 10mA sensitivity is suitable for humid environments to enhance people's safety• Its 300mA and 500mA ‘Selective’ versions ensure selectivity to limit the tripping to the device• Its Super Immunized technology (-SI) associated with a protection class Type A will limit nuisance tripping and non-tripping in harsh electromagnetic conditions and polluted atmospheres• Proven robustness with 20,000 mechanical cycles and up to 15,000 electrical cycles

Features

Facts about iID RCCB

• Compliant with IEC/EN61008-1 and IEC/EN62423 (for Type B) • Voltage-independent technology compliant with IEC/EN61008-2-1 • Available in 2P and 4P from 16 to 100A • Sensitivity: 10, 30, 300 and 500mA • Available in Type AC, Type A, Type A-SI, Type B-EV, and Type B-SI • Tripping time: instantaneous or selective • Insulation voltage (Ui): 500V • Pollution Degree: 3 • Rated impulse withstand voltage (Uimp): 6kV • Test button • Operating temperature: from -5°C to +60°C for Type AC, and from -25°C to +60°C for Type A and A-SI • Wide range of tripping coil auxiliaries (iMN, iMNx, iMSU, iMX+OF..) • Wide range of indicating auxiliaries (iOF, iSD, iOF+SD24..)
