Where to find the drawings for the ReactiVar Capacitor Bank Split Core Current Transformer?

Issue
Where to find the drawings for the ReactiVar Capacitor Bank Split Core Current Transformer?

Product Line
Current Transformer
ReactiVar Capacitor Bank

Environment
Drawings

Cause
Looking for information regarding the split core current transformer, 12.5 VA, 1500:5 A, 7x4" (Part Number: TRAI1500SC07)

Resolution
Please see below the drawings containing details about the split core current transformer (Part Number: TRAI1500SC07):
Part Number: TRAI1500SC07 drawing

Released for: Schneider Electric Canada

Published on:2018-11-27Last Modified on:2025-05-14
