Issue:
Connecting a Wye source to a Delta primary
Product Line:
Square D Transformers
Environment:
Transformer Wiring
Resolution:
A Wye Source can be connected to the Primary side of a Delta transformer. The neutral would have to be left out and the 3 hot legs would have to be connected on the Primary taps based on the wiring diagram provided for the transformer.
Connecting a Wye source to a Delta primary
Product Line:
Square D Transformers
Environment:
Transformer Wiring
Resolution:
A Wye Source can be connected to the Primary side of a Delta transformer. The neutral would have to be left out and the 3 hot legs would have to be connected on the Primary taps based on the wiring diagram provided for the transformer.
Released for: Schneider Electric Canada
