Question 1

How to Download Marine Certificate for Compact NSX from SE Website

Accepted Answer

You can download the Compact NSX marine certificate via SE website by following the instructions below: 1) Go to your local SE Website: Singapore: se.com/sg Philippines: se.com/ph Malaysia: se.com/my Then at the SE website, click on the floating green icon for the support center. 2) Under support center menu, click the link for "Document and Software Download" 3) We will then be directed to "Product Documentation and Software Downloads" page, from there kindly click the link for "Conformity Assessments". 4) Under Conformity Assessments page, type in the relevant keywords of the certificate in the search bar then click on search. 5) Under results you may browse on the different relevant files then choose the most appropriate as per file name shown, lastly click on download.

Question 2

How to choose the correct Residual Current Circuit Breaker (RCCB) for my application?

Accepted Answer

Specification RequirementsFor us to identify the correct Residual Current Circuit Breaker (RCCB), we will be needing the following information:-No of poles:-Earth Leakage Sensitivity:-Ampere Rating:-Operating Voltage:-Type: (if unsure of RCCB Type, see chart below)Once we have these information, you may proceed to the respective product selector per country:Singapore: https://www.se.com/my/en/product-range/7559-acti-9-iidMalaysia: https://www.se.com/sg/en/product-range/7559-acti-9-iidPhilippines: https://www.se.com/ph/en/product-range/7559-acti9-iid​​​​​​How to use Product Selector:1. Click on the Product Selector on the webpage:2. Input all the information that we've gathered earlier, for example, we are looking for the following specification:-No of poles: 4 Poles-Earth Leakage Sensitivity: 100mA-Type: AC-Ampere Rating: 63A-Operating Voltage: 380VacHow to choose product using Filter on Acti 9 iID page:If there's a problem with the configurator, you may resort to the 2nd method which is to configure on the page's filters as shown below:Note: If the product is not found on the product selector or you're having issues with the tool, please contact your country's customer care center to seek Technical Support

Question 3

How do I update my Smart-UPS firmware using the command line interface of my Network Management Card?

Accepted Answer

Issue:Because the Firmware Upgrade Wizard is the most universal and preferred method of updating, we recommend using the APC Firmware Upgrade Wizard whenever possible. The APC Firmware Upgrade Wizard guides you through the update process and provides a consistent update experience. The Firmware Upgrade Wizard is available in FA279197. Instructions are being provided here for users that are unable use the Firmware Upgrade Wizard and wish to update their Smart-UPS Firmware using command line tools and an APC Network Management Card (NMC). For those who wish to update their Smart-UPS Firmware using the NMC’s web interface, see FA170679.Product Line:Smart-UPS models with the prefixes SMT, SMX, SRT, SRTL, XU, and XP with a SmartSlot or Embedded NMC. If the ID of your UPS is not available in the table below, it means there are no firmware updates available for that UPS at this time. Environment: Command line terminal emulator and file transfer toolsSupported UPS model listed aboveUPS Network Management Card 2 (AP9630, AP9630CH, AP9631, AP9631CH, or embedded NMC2) with SUMX application firmware v6.4.0 or higher UPS Network Management Card 3 (AP9640, AP9641, AP9643, or embedded NMC3) with SU application firmware 1.0 or higherCorrect firmware file for the particular UPS available in the table below Resolution:Follow the steps below to determine your current NMC type and firmware revision, select the proper UPS firmware image, and update the UPS firmware via the Network Management Card’s Command Line Interface (CLI). Step 1 - Using an SSH client of your choice, connect to the IP address of the Network Management Card.Note: If required, Open SSH can be added using Windows Manage Optional Features.Example of using Windows Command Prompt to connect via SSH:ssh -c aes256-cbc apc@10.0.0.1Notes: This SSH command is for OpenSSH. The command may differ depending on the SSH tool used.The username may be different that the “apc” username used in this example. Using the web interface of the NMC, navigate to the “SSH Host Key” in the “Console” found in the “Network” section of the “Configuration” menu. Verify and take note of the SSH Key.Compare the SSH key to the RSA fingerprint displayed in the command line terminal window. To display the fingerprint in the same format as shown in the NMC web interface, the <-o FingerPrintHash=md5> argument can be used. Example:ssh -c aes256-cbc -o FingerPrintHash=md5 apc@10.0.0.1Notes: Telnet can be used if enabled, but it is not recommended due to lack of encryption, and the examples shown here are just for reference.Example of using Windows Command Prompt to connect via Telnet: From a computer that has access to the network on which the NMC is installed, at a command prompt, type telnet and the IP address for the NMC (for example, telnet 10.216.253.128, when the NMC uses the default Telnet port of 23), and press ENTER.This example works for command prompt based Telnet clients. The commands may differ for different Telnet clients. If the NMC uses a non-default port number (from 5000 to 32768), you must include a colon or a space, depending on your Telnet client, between the IP address (or DNS name) and the port number. (These are commands for general usage: some clients don’t allow you to specify the port as an argument and some types of Linux might want extra commands). Enter the user name and password.Step 2 - Check if you have a Network Management Card 2 running Smart-UPS / Matrix Application, or a Network Management Card 3 running Smart-UPS Application and ensure there are no active alarms reported.Use the command to display the Network Management Card application module:Network Management Card 2 installed in a Smart-UPS uses “sumx” Application Module: Network Management Card 3 installed in a Smart-UPS uses “su” Application Module:Use the command to ensure there are no active alarms:Step 3 - If using Network Management Card 3, go to Step 4.If using Network Management Card 2: Verify the firmware revision of your Network Management Card. The firmware must be v.6.4.0 or higher, but we recommend you always run the latest available NMC firmware. To update the firmware of your Network Management Card, refer to FA156047.Use the command to display the Network Management Card firmware version:Step 4 - IMPORTANT: For Smart-UPS Ultra models with ID 1226 & 1227, the firmware of the Network Management Card must be updated to version 2.5.4.4 or later before updating the UPS firmware. Refer to FA156047 to update the firmware of the Network Management Card. Note: always download the latest NMC firmware for SUCAN application from se.com: Step 5 – Identify the correct UPS Firmware file. Use the command.Identify the "ID" number to select the proper firmware file for your UPS. For example, for a UPS with ID 1024 the proper filename will be SRTL1024UPS_xx-x.enc Download the appropriate firmware file available in the table below. The "ID" is a unique identifier for the hardware platform of your UPS. You need to use the "ID" number to make sure to select the correct firmware file. A particular UPS model may have different "ID" numbers depending on when it was manufactured, or its current firmware version. Always check the "ID" number of the UPS before starting the update, and ensure you use a firmware file with the compatible ID. If the incorrect file is used, the update will be refused, and will need to be restarted using the correct firmware file. Use the table below to determine the correct firmware file for your UPS. Click here to view details UPSSeriesUPSIDFirmware FileLatest FirmwareVersionReleaseNotesFirmwareUpdate withOutput OnAvailableCrypto-graphycallySignedFirmwareUpdatevia NMCSCL1029SCL1029UPS_15-6.encUPS 15.6YesYesEnabledSCL1048SCL1048UPS_16-6.encUPS 16.6YesYesEnabledSMC1005SMC1005UPS_15-1.encUPS 15.1NoNoConfigurableSMT1015SMT1015UPS_18-0.encUPS 18.0YesYesConfigurableSMT1027SMT1027UPS_18-0.encUPS 18.0YesYesConfigurableSMT1031SMT1031UPS_15-6.encUPS 15.6YesYesConfigurableSMT1039SMT1039UPS_15-5.encUPS 15.5NoYesConfigurableSMT1040SMT1040UPS_15-0.encUPS 15.0NoNoConfigurableSMT1041SMT1041UPS_15-0.encUPS 15.0NoNoDisabledSMT1050SMT1050UPS_16-6.encUPS 16.6YesYesConfigurableSMT1059SMT1059UPS_16-5.encUPS 16.5YesYesConfigurableSMT1060SMT1060UPS_02-0.encUPS 02.0YesYesConfigurableSMT17SMT17UPS_07-1.encUPS 07.1NoNoEnabledSMT18SMT18UPS_15-1.encUPS 15.1NoNoConfigurableSMT20SMT20UPS_15-0.encUPS 15.0NoNo ConfigurableSMTL1026SMTL1026UPS_15-5.encUPS 15.5YesYesConfigurableSMTL1047SMTL1047UPS_16-5.encUPS 16.5YesYesConfigurableSMTL1064SMTL1064UPS_01-8.encUPS 01.8YesYesConfigurableSMX1003SMX1003UPS_15-0.encUPS 15.0NoNoConfigurableSMX1031SMX1031UPS_15-6.encUPS 15.6NoYesConfigurableSMX1050SMX1050UPS_16-6.encUPS 16.6NoYesConfigurableSMX20SMX20UPS_15-0.encUPS 15.0NoNoConfigurableSMX23SMX23UPS_15-0.encUPS 15.0NoNoConfigurableSRT1001*SRT1001UPS_02-9.encUPS 02.9NoNoEnabledSRT1002SRT1002UPS_15-1.encUPS 15.1NoNoDisabledSRT1010SRT1010UPS_15-5.encUPS 15.5NoYesEnabledSRT1013SRT1013UPS_15-1.encUPS 15.1NoNoDisabledSRT1014SRT1014UPS_15-1.encUPS 15.1NoNoDisabledSRT1019SRT1019UPS_15-5.encUPS 15.5NoYesEnabledSRT1020SRT1020UPS_15-8.encUPS 15.8NoYesEnabledSRT1021SRT1021UPS_15-6.encUPS 15.6NoYesEnabledSRT1024SRT1024UPS_15-6.encUPS 15.6NoYesEnabledSRT1025SRT1025UPS_15-5.encUPS 15.5NoYesEnabledSRTL1024SRTL1024UPS_15-6.encUPS 15.6NoYesEnabledSRTL1034SRTL1034UPS_10-1.encUPS 10.1YesYesEnabledSRTL1035SRTL1035UPS_10-1.encUPS 10.1YesYesEnabledSRTL1062SRTL1062UPS_10-1.encUPS 10.1YesYesEnabledSRTL1063SRTL1063UPS_10-1.encUPS 10.1YesYesEnabledSRTL1226**SRTL1226UPS_3-8.encUPS 03.8NoYesEnabledSRTL1227**SRTL1227UPS_01-2.encUPS 01.2NoYesEnabledSRYL1225***SRYL1225UPS_18-0.encUPS 18.0NoYesEnabledXP1016XP1016UPS_15-1.encUPS 15.1NoNoEnabledXU1017XU1017UPS_15-7.encUPS 15.7NoYesDisabledXU1025XU1025UPS_15-5.encUPS 15.5NoYesEnabledXU1033XU1033UPS_15-7.encUPS 15.7NoYesDisabled Notes: *For SRT UPS models with ID of 1001, the UPS firmware must be updated in two steps. First update the UPS firmware using SRT1001UPS_02-9.enc. This will change the UPS ID to 1013. Once the update to UPS 02.9 is completed, perform the firmware update again using SRT1013UPS_15-0.enc.** For SRTL UPS models with ID 1226 & 1227, always perform a Logic Reset or "Brain Dead" before initiating the firmware update. Refer to FAQ000269051 for more information.*** For SRTL UPS models with ID 1225, refer to FAQ000261838 for additional update instructions.It is not recommended to perform a firmware downgrade to a lower firmware version.In rare situations, the UPS firmware update may not install automatically after the firmware file was transferred to the UPS. Refer to FAQ000258690 to complete the UPS firmware update.For more information about enabling or disabling firmware updates via the NMC for the UPS models that support this feature, refer to FAQ00024438.Once firmware updates via the NMC have been disabled, attempts to update the UPS firmware using the NMC will be refused:For SRYL (Smart UPS Modular Ultra), if upgrading from 13.2 or greater you may put the UPS into Manual Bypass. See Set the UPS to Manual Bypass Mode section in the Smart UPS Modular Ultra Manual. Step 6 – The majority of UPS models support firmware update with output on. Refer to the above table, and if you have a UPS that supports firmware update with output on, go to Step 7.NOTE: For UPS devices that require the UPS output to be off before initiating the update, ensure that network access is not dependent on the UPS for power, when updating via the Network Management Card.If network access is dependent on the UPS for power, refer to FA279197 for instructions on updating the UPS firmware using the Firmware Upgrade Wizard.If network access is not dependent on the UPS for power, ensure the attached load is correctly shut down before proceeding with turning off the UPS output.Use the command to turn off the UPS output, then use the command to verify the UPS output status:Step 8 Via SCP:Use the command to disconnect from the SSH or Telnet session:Copy the UPS firmware file to the NMC using the following command:NOTE: This SSH command is for OpenSSH. The command may differ depending on the SSH tool used. In this example, the file will be copied to the “tmp” folder on the NMC.Via FTP:FTP may be disabled by default on the NMC, and must be enabled before continuing.Use the command to enable FTP and use the command followed by to reboot the NMC and apply the changes.Use the command to disconnect from the SSH or Telnet session:Using an FTP client of your choice, FTP the UPS firmware file onto the “tmp” folder on the NMC.Here’s an example of loading a UPS firmware file onto the “tmp” folder on the NMC using Windows Command Prompt:ftp User (:(none)): NMC UsernamePassword: NMC Passwordftp> binftp> hashftp> cd tmpftp> put “”ftp> quitStep 9 - Reconnect to the NMC, and use the command followed by the command to verify that the file has been copied to the “tmp” folder on the NMC:Initiate the UPS Firmware Update using the command to check the status of the UPS Firmware Update:The update may take several minutes. Once the command returns “Status: No firmware update is in progress”, the UPS firmware update is completed.Verify that the new UPS firmware version is shown using the command:If the update does not complete, or if any errors are displayed, ensure that the conditions in Step 2 are met. Try updating the UPS firmware with the UPS output turned off. If no alarms are shown, try updating the UPS firmware using the Firmware Upgrade Wizard, which can be found in FA279197 .Step 10 – If the UPS output was turned off in Step 6, the UPS output should now be turned back on.Use the command to turn the UPS output back on.The attached load can now be turned on.For any issues encountered during the update process or any additional questions, please contact APC Tech Support.

Question 4

Material Safety Data Sheets (MSDS) or Safety data Sheets (SDS) for Batteries Used in APC UPS 1 Phase Systems

Accepted Answer

Issue:I require the Material Safety Data Sheet (MSDS) or Safety Data Sheet (SDS) for various APC single phase UPS products.Product Line:All APC Single phase UPSEnvironment: All APC UPSCause: The majority of batteries used in APC by Schneider Electric Uninterruptible Power Supply (UPS) systems and Replacement Battery Cartridges (RBCs) are contained within cartridges and are sealed, non-spillable, maintenance-free lead acid batteries. The batteries are a manufactured article consisting of a plastic, sealed case, terminals and flame arrestor vent caps. Case color varies. The electrolyte is contained within the case and consists of the electrolyte held captive in an adsorbed glass mat (AGM) or gel matrix. There is no “free” electrolyte to leak out of the case. Under normal use and handling, there is no contact with the internal components of the battery or the chemical hazards. Under normal use and handling, these products do not emit regulated or hazardous substances. The design life of a sealed lead acid battery is 3-5 years depending on environmental factors. Using the batteries past the end of it’s design life can result in electrolyte leakage. In a few cases, Replacement Battery Cartridges (RBCs) containing High Power Lithium Ion Cell, Phosphate-Based are also used. These batteries are used stricitly in select models found in the Back-UPS Connect family. Resolution: North America UPS Battery MSDS Back UPS, Smart UPS, Easy UPS, Symmetra LX, Symmetra RMAll VRLA RBC, SYBT2, SYBT5Click Here Smart UPS Line Interactive Lithium Ion UPS Battery MSDS UN38.3 SCL500RM1NC / SCL500RM1UC / SCL500RM1UNCN/AClick HereClick HereSMTL750RM2UC / SMTL1000RM2UC / SMTL1500RM2UC N/AClick HereClick HereSMTL2200RMXXX / SMT2K2RMXXX / SMT3000RMXXX / SMT3KRMXXXAPCRBC174-LIClick HereClick Here Smart UPS Ultra UPS Battery MSDS UN38.3 SRTL2K2RM1UC / SRTL2K2RM1UNC / SRTL3KRM1UNC / SRTL3KRM1UWCAPCRBC173-LIClick HereClick HereSRTL50RMBP1U-LIN/AClick HereClick HereSmart UPS Ultra 5K-10K / SRTL180RM2UBP / Smart UPS Modular UltraSRYLBMClick HereClick Here Easy UPS Online Lithium Ion UPS Battery MSDS UN38.3 SRVSL1KRARK / SRVSL2K2RARK / SRVSL3KRARKRBCV181-LI / RBCV182-LI / RBCV183-LIClick HereClick HereSRVL48RMBP2U N/AClick HereClick HereSRVL48RMBP3UN/AClick HereClick Here Schneider Off-Grid UPS Battery MSDS UN38.3 PPS330N/AClick HereClick HerePPS500N/AClick HereClick HerePPS730N/AClick HereClick Here Microsoft Surface Hub 2S & Surface Hub 3 UPS Battery MSDS UN38.3 CSH2Click HereClick Here EU / International UPS Battery MSDS Back UPS, Smart UPS, Easy UPS, Symmetra LX, Symmetra RMAll VRLA RBC, SYBT2, SYBT5Click Here Smart UPS Line Interactive Lithium Ion UPS Battery MSDS UN38.3 SCL500RMI1UC / SCL500RMI1UNCN/AClick HereClick HereSMTL750RMI2UC / SMTL1000RMI2UC / SMTL1500RMI2UC N/AClick HereClick HereSMTL2200RMIXXX / SMT2K2RMIXXX / SMT3000RMIXXX / SMT3KRMIXXXAPCRBC174-LIClick HereClick Here Smart UPS Online Lithium Ion UPS Battery MSDS UN38.3 SRTL1000RMXLI / SRTL1500RMXLIXBP48RM1U-LIClick HereClick HereSRTL2200RMXLI / SRTL3000RMXLIXBP48RM1U2-LIClick HereClick HereSRTL1000RM4UXLI / SRTL1500RM4UXLI / SRTL2200RM4UXLI / SRTL3000RM4UXLIXBP48RM2U-LIClick HereClick Here Smart UPS Ultra UPS Battery MSDS UN38.3 SRTL2K2RM1UIC / SRTL2K2RM1UINC / SRTL3KRM1UINC / SRTL3KRM1UICAPCRBC173-LIClick HereClick HereSRTL50RMBP1U-LIN/AClick HereClick HereSmart UPS Ultra 5K-10K / SRTL180RM2UBP SRYLBMClick HereClick Here Easy UPS Online Lithium Ion UPS Battery MSDS UN38.3 SRVL1KRIRK / SRVSL1KRIRK / SRVL2K2RIRK / SRVSL2K2RIRK / SRVL3KRIRK / SRVSL3KRIRKRBCV181-LI / RBCV182-LI / RBCV183-LIClick HereClick HereSRVL48RMBP2UN/AClick HereClick HereSRVL48RMBP3UN/AClick HereClick Here Schneider Off-Grid UPS Battery MSDS UN38.3 PPS330N/AClick HereClick HerePPS500N/AClick HereClick HerePPS730N/AClick HereClick Here Microsoft Surface Hub 2S & Surface Hub 3 UPS Battery MSDS UN38.3 CSH2N/AClick HereClick Here APC Back UPS Connect UPS Battery MSDS UN38.3 CP12036LIN/AClick HereClick Here

Question 5

Product Environment Profile for PM8000

Accepted Answer

IssueUser is looking for Product Environment Profile documentation for PM8000 metersProduct LinePM8000 series meter Environment PM8000 series meter CauseNot able to find the product environment profiles for the PM8000. ResolutionProduct Environment Profile for PM8000 meters are attached belowDocument ENVPEP1406023EN.pdf is for PM8240 meterDocument ENVPEP1406022EN.pdf is for PM8243 meterDocument ENVPEP1406040EN.pdf is for PM89RD96 Remote Display for PM8000 meters

Question 6

What is Modbus and How does it work?

Accepted Answer

What is Modbus? Modbus is a serial communication protocol developed by Modicon published by Modicon® in 1979 for use with its programmable logic controllers (PLCs). In simple terms, it is a method used for transmitting information over serial lines between electronic devices. The device requesting the information is called the Modbus Client and the devices supplying information are Modbus Servers. In a standard Modbus network, there is one Client and up to 247 Servers, each with a unique Server Address from 1 to 247. The Client can also write information to the Servers.The official Modbus specification can be found at https://modbus.org/ What is it used for? Modbus is an open protocol, meaning that it's free for manufacturers to build into their equipment without having to pay royalties. It has become a standard communications protocol in industry, and is now the most commonly available means of connecting industrial electronic devices. It is used widely by many manufacturers throughout many industries. Modbus is typically used to transmit signals from instrumentation and control devices back to a main controller or data gathering system, for example a system that measures temperature and humidity and communicates the results to a computer. Modbus is often used to connect a supervisory computer with a remote terminal unit (RTU) in supervisory control and data acquisition (SCADA) systems. Versions of the Modbus protocol exist for serial lines (Modbus RTU and Modbus ASCII) and for Ethernet (Modbus TCP). How does it work? Modbus is transmitted over serial lines between devices. The simplest setup would be a single serial cable connecting the serial ports on two devices, a Client and a Server. The data is sent as series of ones and zeroes called bits. Each bit is sent as a voltage. Zeroes are sent as positive voltages and a ones as negative. The bits are sent very quickly. A typical transmission speed is 9600 baud (bits per second). What is hexadecimal? When troubleshooting problems, it can be helpful to see the actual raw data being transmitted. Long strings of ones and zeroes are difficult to read, so the bits are combined and shown in hexadecimal. Each block of 4 bits is represented by one of the sixteen characters from 0 to F. Each block of 8 bits (called a byte) is represented by one of the 256 character pairs from 00 to FF. How is data stored in Standard Modbus? Information is stored in the Server device in four different tables. Two tables store on/off discrete values (coils) and two store numerical values (registers). The coils and registers each have a read-only table and read-write table. Each table has 9999 values. Each coil or contact is 1 bit and assigned a data address between 0000 and 270E. Each register is 1 word = 16 bits = 2 bytes and also has data address between 0000 and 270E. Coil/Register Numbers can be thought of as location names since they do not appear in the actual messages. The Data Addresses are used in the messages. For example, the first Holding Register, number 40001, has the Data Address 0000. The difference between these two values is the offset. Each table has a different offset. 1, 10001, 30001 and 40001. What is the Server ID? Each server in a network is assigned a unique unit address from 1 to 247. When the client requests data, the first byte it sends is the Server address. This way each server knows after the first byte whether or not to ignore the message. What is a function code? The second byte sent by the Client is the Function code. This number tells the server which table to access and whether to read from or write to the table. What is a CRC? CRC stands for Cyclic Redundancy check. It is two bytes added to the end of every modbus message for error detection. Every byte in the message is used to calculate the CRC. The receiving device also calculates the CRC and compares it to the CRC from the sending device. If even one bit in the message is received incorrectly, the CRCs will be different and an error will result. . What are the formats of Modbus commands and responses? What are data types? The example for FC03 shows that register 40108 contains AE41 which converts to the 16 bits 1010 1110 0100 0001 Great! But what does it mean? Well, it could mean a few things. Register 40108 could be defined as any of these 16-bit data types: A 16-bit unsigned integer (a whole number between 0 and 65535) register 40108 contains AE41 = 44,609 (hex to decimal conversion) A 16-bit signed integer (a whole number between -32768 and 32767) AE41 = -20,927 (hex to decimal conversion that wraps, if its over 32767 then subtract 65536) A two character ASCII string (2 typed letters) AE41 = ® A A discrete on/off value (this works the same as 16-bit integers with a value of 0 or 1. The hex data would be 0000 or 0001) Register 40108 could also be combined with40109 to form any of these 32-bit data types: A 32-bit unsigned integer (a number between 0 and 4,294,967,295) 40108,40109 = AE41 5652 = 2,923,517,522 A 32-bit signed integer (a number between -2,147,483,648 and 2,147,483,647) AE41 5652 = -1,371,449,774 A 32-bit double precision IEEE floating point number. This is a mathematical formula that allows any real number (a number with decimal points) to represented by 32 bits with an accuracy of about seven digits. AE41 5652 = -4.395978 E-11 Here is a spreadsheet IEEE float calculator for inputs of 4 bytes or 2 words. To download a copy, right click and select Save Target As... A four character ASCII string (4 typed letters) AE41 5652 = ® A V R More registers can be combined to form longer ASCII strings. Each register being used to store two ASCII characters (two bytes). What is byte and word ordering? The Modbus specification doesn't define exactly how the data is stored in the registers. Therefore, some manufacturers implemented modbus in their equipment to store and transmit the higher byte first followed by the lower byte. (AE before 41). Alternatively, others store and transmit the lower byte first (41 before AE). Similarly, when registers are combined to represent 32-bit data types, Some devices store the higher 16 bits (high word) in the first register and the remaining low word in the second (AE41 before 5652) while others do the opposite (5652 before AE41) It doesn't matter which order the bytes or words are sent in, as long as the receiving device knows which way to expect it. For example, if the number 29,235,175,522 was to be sent as a 32 bit unsigned integer, it could be arranged any of these four ways. AE41 5652 high byte first high word first 5652 AE41 high byte first low word first 41AE 5256 low byte first high word first 5256 41AE low byte first low word first What is a Modbus Map? A modbus map is simply a list for an individual server device that defines - what the data is (eg. pressure or temperature readings) - where the data is stored (which tables and data addresses) - how the data is stored (data types, byte and word ordering) Some devices are built with a fixed map that is defined by the manufacturer. While other devices allow the operator to configure or program a custom map to fit their needs. What is the difference between Modbus ASCII and Modbus RTU? Modbus RTU and Modbus ASCII talk the same protocol. The only difference is that the bytes being transmitted over the wire are presented as binary with RTU and as readable ASCII with Modbus RTU. important to note about RTU is that the RTU message does not have a Start_of_text indication. The receiving party in the communications uses a "silent" time in order to determine the start of a new message. ASCII does have a start-of-text token. Binary messages are shorter than ASCII and therefore theoretically faster to transmit/receive. You may be happy to see update rates of about 100 ms in your HMI/SCADA and could choose either communication.Summary:- use RTU is possible- use ASCII in case RTU is giving timeout problems on WinNT or when using slow communications media like 300 bps or dialup modems Most OPC Servers for Modbus support ASCII as well as RTU communications.. What are extended register addresses? Since the range of the analog output holding registers is 40001 to 49999, it implies that there cannot be more than 9999 registers. Although this is usually enough for most applications, there are cases where more registers would be beneficial. Registers 40001 to 49999 correspond to data addresses 0000 to 270E. If we utilize the remaining data addresses 270F to FFFF, over six times as many registers can be available, 65536 in total. This would correspond to register numbers from 40001 to 105536. Many modbus software drivers (for Client PCs) were written with the 40001 to 49999 limits and cannot access extended registers in server devices. And many server devices do not support maps using the extended registers. But on the other hand, some server devices do support these registers and some Client software can access it, especially if custom software is written. How does 2-byte server addressing work? Since a single byte is normally used to define the server address and each server on a network requires a unique address, the number of server on a network is limited to 256. The limit defined in the modbus specification is even lower at 247. To get beyond this limit, a modification can be made to the protocol to use two bytes for the address. The client and the servers would all be required to support this modification. Two byte addressing extends the limit on the number of servers in a network to 65535. By default, the Simply Modbus software uses 1 byte addressing. When an address greater than 255 is entered, the software automatically switches to 2 byte addressing and stays in this mode for all addresses until the 2 byte addressing is manually turned off. How can you send events and historical data? Enron Modbus includes commands for moving events and historical data.. What is Enron Modbus? Enron Modbus is a modification to the standard Modicon modbus communication protocol developed by Enron Corporation. See Enron Modbus for details.

Question 7

Warranty Support and Verification

Accepted Answer

I have a 1PH APC Product. What is your warranty policy? Product Line APC equipment purchased from qualified and legitimate resellers and/or distributors. Resolution At APC by Schneider Electric, we value your business and are committed to ensuring your devices are properly registered and supported. To verify your unit’s warranty status or correct any details, please use our online services:🔗 Check Warranty Status Warranty Policy References For your convenience, warranty policies are outlined in the following resources: APC Back-UPS™ and APC Portable Power Station (Schneider OffGrid):🔗 View FAQ APC Smart-UPS™:🔗 View FAQ APC Rack PDU, Rack ATS, and SmartSlot™ Cards:🔗 View FAQ APC Symmetra LX and RM™, including compatible replaceable modules:🔗 View FAQ Warranty Discrepancies and Support In rare cases, warranty records may not reflect the actual purchase date. If you notice any discrepancies or would like to confirm or correct your warranty details, please contact us: 📞 Phone: 1-800-800-4272💬 Live Chat: Chat with Technical Support Please have the following information ready: Model or SKU numberSerial Number (SN) of the device or accessory Note: The location of the serial number may vary depending on the model. Our support team can assist you in locating it. Warranty Disclaimer Schneider Electric reserves the right to refuse warranty correction for any unit or device not purchased through authorized resellers or legitimate distributors. To ensure eligibility for warranty support, customers may be required to present proof of purchase from a recognized sales channel. For a list of authorized resellers and distributors, please visit: 🔗 Schneider Electric Partner Locator

Question 8

How to Download Declaration of Conformity from SE Local Website

Accepted Answer

You can get the Declaration of Conformity for a specific SE product by following the instructions below: 1) Go to your local SE Website: Singapore: se.com/sg Philippines: se.com/ph Malaysia: se.com/my Then at the search bar, type in your desired product part number and click on search and lastly select view details from the product popup. 2) From the product page, scroll down to Documents section then select filter for Conformity Assessments then lastly click download for the appropriate declaration file.

Question 9

What is the selection criterion of Circuit Breakers for the Capacitor bank application.

Accepted Answer

The selection should be done after derating the Circuit Breaker taking into consideration voltage variation and capacitors tolerances that could increase nominal current up to 1.5In. The Derating factor of 1.5In Where In = Q/ ( Square root of 3 ) Un Q = Capacitor Power Un = Nominal Voltage Choose the Micrologic with delay time selection, so that the Circuit Breaker does not trip due to initial high inrush current. Also to be taken into account are the parameters like supply frequency, operating voltage & harmonics level of the power system for such application. Refer the attached sheet for further details for selection of Circuit Breaker for Capacitor duty application. Note: Use the phase barrier between the phases in Circuit Breaker to prevent flashover due to heavy inrush current.
