Issue:
Repair parts list for CD223N, series F1 and F3
Product Line:
Safety Switches
Resolution:
The parts listed here are the only field replaceable parts.
Line base assembly - 4056609450
Load base assembly - 4056609550
Arc shield - 4056601901
Mechanism assembly - 4056647650
Handle assembly - 4056610350
Lockplate - 4056605801
Lug assembly - 4025101851
Neutral assembly - SN0610
Base assembly mounting screws - 4020515101 (3 required for line base & 2 required for load base)
Arc shield mounting screw - 4020514501
Neutral bonding assembly - 4028365650
lockplate moungting screw - 2299940562 (2 required)
Lug assembly mounting screw - 4020514202
