Discover PowerLogic Current Sensors
Discover PowerLogic Current Sensors
Enhance meter efficiency and safety
These sensors are a comprehensive offer, ideally suited for use throughout the entire low voltage field, from 50A to 2400A. They deliver at the secondary a Current (0-5A) or Voltage (0-0.333V) proportional to the current measured at the primary. They can be used in combination with measurement devices (switchboard instrumentation, kilowatt-hour meters, power-monitoring units).
Benefits of PowerLogic Current Sensors
Benefits of PowerLogic Current Sensors
Adaptable
Includes everything you need for an easy installation in both retrofit and greenfield applications.
Accurate
Ensures reliable monitoring of your panel board with accurate meter measurements between 0.5% and 1%.
Reliable
Offers wide-ranging primary currents that meet the latest safety standards to help ensure reliable measurements.
Sustainable
Ensures energy efficiency, durability, and recyclability as a Green Premium label product.
Features
Features
Split-core current sensors
- Ampacities from 50A to 2400A
- Fits conductors from 10x10mm to 62x145mm
- Operable in temperatures from 32° F to 158° F (0° C to 70° C) with relative humidity > 95%
Solid-core current sensors
- Ampacities from 50A to 400A
- Fits conductors from 10x32mm to 55x165mm
- Operable in temperatures from -40° F to 185° F (-40° C to 85° C) with relative humidity > 95%
Rogowski coils
- Coil measurement range from 50A up to 5000A
- Coil diameter from 96mm to 287mm (open coil length from 300mm to 900mm)
- Operable in temperatures from 5° F to 140° F (-15° C to 60° C) with relative humidity > 95%
