What are the repair parts for a D326N, Series E01, E02, & E03?
Issue:
Repair parts
Product Line:
GD Safety Switch
Resolution:
The parts listed here are the only field replaceable parts.
Line base assembly - 4051043451
Load base assembly - 4051043751
Arc supressor - 4051057402
Lug assembly - 8011612250
Neutral assembly - D600SN
Base assembly mounting screws - 2142720241 (6 required for line base and 7 required for load base)
Arc supressor mounting screw - 4020508201
Lug mounting nut - 2342702800
Neutral assembly mounting screw - 4020506501 (4 required)
Neutral bonding assembly - 4028331250
Cross Arm Insulator - 4051030801 (insulator) and 4051031801 (dust shield - retainer for insulator)
Repair parts
Product Line:
GD Safety Switch
Resolution:
The parts listed here are the only field replaceable parts.
Line base assembly - 4051043451
Load base assembly - 4051043751
Arc supressor - 4051057402
Lug assembly - 8011612250
Neutral assembly - D600SN
Base assembly mounting screws - 2142720241 (6 required for line base and 7 required for load base)
Arc supressor mounting screw - 4020508201
Lug mounting nut - 2342702800
Neutral assembly mounting screw - 4020506501 (4 required)
Neutral bonding assembly - 4028331250
Cross Arm Insulator - 4051030801 (insulator) and 4051031801 (dust shield - retainer for insulator)
Released for: Schneider Electric USA
