What are the repair parts for the HU362DS, series F5? (may be shown as F05)
Issue:
Field replaceable parts for HU362DS series F05 / F5
Product Line:
Safety Switch
Environment:
Heavy Duty Safety Switch
Resolution:
The repair parts for the HU362DS, series F5 (F05) are as follows. No other parts are available.
Line Base Assembly - 4056612850 - obsolete use part #4056609150 (arc suppressor not included)
Line Base mounting screw - 4020515101 (3 required)
Arc Suppressor Assembly - HAS0610F (includes arc suppressor and mounting screw)
Lug Assembly - CL0306F (includes 6 lugs)
Mechanism Assembly - 4056646950 (NOTE: Handle Coupling, Cover Interlock Defeat Coupling, and Lockplate Gaskets may also need replacing)
Handle Coupling - 4056699850
Cover Interlock Defeat Coupling - 4056699750
Handle Assembly - 4056779850 (also recommend replacing Lockplate Gaskets)
Lockplate - 4056681201 (also recommend replacing Lockplate Gaskets)
Lockplate Gasket - 4050322803 (2 required)
Lockplate mounting screw - 2194918121 (2 required)
Ground Lug - 4025101652 (2 total required)
Ground Lug Mounting Screw - 4020513503
Released for: Schneider Electric USA
