What tenant circuit breakers can be used with ALL the EZM, 1 phase IN - 1 phase OUT, 125 A branch device meter sockets?
Issue:
Product Features
Product Line:
EZM Metering
Resolution:
ALL the EZM 1 phase IN - 1 phase OUT, 125 A branch device meter sockets use the QO, QO-VH, or QOH, 125 A max tenant circuit breakers. Example catalog number for 125 A - QO2125, QO2125VH, or QOH2125.
NOTE: There is no minimum ampere rating of a 2-pole tenant circuit breaker that can be used, there is only the 125 A maximum. QO-GFI and QO-EPD breakers may also be used on the EZM branch, taking into account the AIR limitation of the QO-GFI/EPD breakers.
Product Features
Product Line:
EZM Metering
Resolution:
ALL the EZM 1 phase IN - 1 phase OUT, 125 A branch device meter sockets use the QO, QO-VH, or QOH, 125 A max tenant circuit breakers. Example catalog number for 125 A - QO2125, QO2125VH, or QOH2125.
NOTE: There is no minimum ampere rating of a 2-pole tenant circuit breaker that can be used, there is only the 125 A maximum. QO-GFI and QO-EPD breakers may also be used on the EZM branch, taking into account the AIR limitation of the QO-GFI/EPD breakers.
Released for: Schneider Electric USA
