Canalis KBA

Canalis KBA busbar trunking is a full and compatible range for lighting systems in small and medium-height buildings (garages, workshop, supermarket). It’s compatible with Canalis KBL lights, pre-mounted and pre-cabled in the factory

Technical characteristics of Canalis KBA:

• Length of busbar trunking components: 2 or 3m

• Rated service current: 25 and 40A

• Rated tap-off units current: 10 and 16A

• Rated insulating voltage: 690V

• Number of circuits: 1 circuit (2 or 4 conductors)

• Protection index: IP55

• Surface treatment: galvanised or white Ral 9010

• Regulations: compliant with IEC 60439-2

Technical characteristics of Canalis KBL:

• Power: from 2x35W to 2x80W with ferro-magnetic or electronic ballast

• for T5 or T8 tubes

• Protection index: IP20 or IP55

• Modular and upgradeable system

• Quick and easy assembly

• Flexible: possibility to install a light right where it is needed.

• Halogen free: Canalis does not emit any fumes or toxic gases in the event of fire

• High protection index IP 55 for all types of buildings

• Dismantled, re-used and entirely recyclable

• Industrial buildings: garages, workshops, farm buildings, logistic centers, greenhouses, etc.

• Commercial centres: Hyper / supermarket, department store

• Tertiary buildings: exhibition hall, conference centre
