EcoStruxure Power Build | MV Configuration Software

EcoStruxure Power Build Medium Voltage

Discover our free online configuration and quotation software for medium-voltage switchboards that helps panel builders be more efficient in the build process of MV switchgear and components (transformers, protection relays).
Try a free demo Access the full software

Configure your MV switchboard in minutes
EcoStruxure Power Build Medium Voltage (formally known as Ecoreal MV) is an all-in-one online configuration and quotation software dedicated to panel builders. It simplifies medium-voltage switchgear and components configuration, quotation and order execution. You can be more agile, more productive and achieve more sales.

• Reduced risk of errors

• Re-use previously saved configurations and customize them to save time

• Intuitive user interface

• Precise, technically-validated 2D layout exports
• Single Line Diagram (SLD) and Bill of Material (BOM) are automatically generated

• All the documents you need for ordering, ready to export

• Save and reuse your projects

• Easy to use

• Always up to date

• Accurate and error-free BID and BOM documents are generated and can be modified, even at the last minute

• Configure switchboard ranges: SM6-24, SM6-36, RM6, PIX Easy FR , PIX Easy MR, PIX ROF, Premset, MCSet

• Circuit breaker ranges: SF, EasyPact Exe, LF, Evolis

• Protection relay ranges: Micom, Sepam, Easergy P3, Easergy P5, Easergy T300 and Vamp

Software features

Easily configure your MV switchgear

• Complete project management
• Use constantly updated technical specification
• Enriched single-line diagram management with free-build mode
• 2D configuration layout (top/front view)
Be prepared to order

• Simply integrable in your current process
• Generate ordering Bill of Materials (BOM)
• Technical specification – obtain an accurate offer documentation

EcoStruxure Power Build
The Ecoreal MV Software has been relaunched as EcoStruxure Power Build Medium Voltage, a part of our Customer Lifecycle Software connected with the EcoStruxure Power Platform. At each step of your project’s lifecycle, these tools will help you design, build, commission, operate and maintain your electrical installation.
Discover the suite
Introducing EcoStruxure™ Power
IoT-connected solutions ready to improve every aspect of your electrical distribution system. Take total control with real-time data and smart analytics for predictive maintenance.
Learn more about EcoStruxure Power
